Help Center150hp 4WD Wheel Tractor
Related Products
-
China Mini 15HP Tractor 4X2 WD, Wheel TractorUS$ 1 - 2MOQ: 1 Set -
TY304 30HP 4X4 Cheap Wheel TractorNegotiableMOQ: 1 Set
-
China JT904 4X4 90HP TractorUS$ 1 - 2MOQ: 1 Set
-
Tractor JT1304,130HP 4X4WDUS$ 1 - 2MOQ: 1 Set
-
China Factory Supply 15HP Mini Farm Garden Tractor, With Plough and TrailerUS$ 1 - 2MOQ: 1 Set
Brief Introduction:
this High horsepower Tractor which from 100HP to 150HP,
With the integrated frame,independent and extensible PTO,the tractor can add the attachment of loading,digging, bulldozing,lifting conveniently. Expand the function of the tractor and improve the utilization ratio of the tractor.
In terms of the parts, the tractor can adopt the mature technology in heavy truck and construction machinery, such as the technologies of disc brake, wet clutch, synchronizer, and oil and gas power. With the development advantage of other industries,the company accelerates to improve the technology of the tractor.
1504 Tractor Standard Configuration:
Shangchai 6-cylinder turbocharger diesel engine, rated power 110kw/150HP, fully enclosed cab, air heater, air conditioning,14F+7R shifts of transmission, shifting synchronizer, integrated frame, driving system with modularized structure,CARRARO front axle,rear axle for engineering machinery,rear double wheels,caliper disc brake,revolution for power output shaft of dual revolution 540/1000r/min, fully hydraulic front wheel steering, three groups of single/dual action hydraulic output, plough depth control method by position,floating control,and suspension mechanism of rear-mounted Category III,twelve pieces of front countweight in 400kgs.
1504 Tractor Main Specification and Technical Parameter:
Item |
Unit |
1504 |
||
Net Power of Engine |
kW(HP) |
110(150) |
||
Driving Method |
|
4x4, Four-wheel drive |
||
Dimension, Length/Width (tread) /Height (Cab Top) |
mm |
5830/2420(3450)/3010 |
||
Wheelbase |
mm |
3080 |
||
Wheelbase of Front Wheel |
mm |
1888-2124 |
||
Wheelbase of Rear Wheel |
mm |
1952-2568 |
||
Minimum Ground Clearances |
mm |
450 |
||
Minimum Steering Circle Radius |
mm |
6900 |
||
Minimum Working Weight |
kg |
6700 |
||
Front Counterweight≤ |
kg |
400 |
||
Rated Traction Force |
kN |
36 |
||
Power Output Shaft |
Model |
|
Independent Rear-mounted |
|
Standard RPM |
r/min |
540/1000 |
||
Maximum Lifting Force |
kN |
31 |
||
Forward Gears |
Low RPM |
The number of stalls |
|
7 |
Driving Speed |
km/h |
2-16 |
||
High RPM |
The number of stalls |
|
7 |
|
Driving Speed |
km/h |
3-29 |
||
Reverse Gears |
The number of stalls |
|
7 |
|
Driving Speed |
km/h |
2-19 |
||
Specification of Tire |
Front Wheel |
|
14.9-26R1 |
|
Rear Wheel |
|
18.4-38R1 |
||
Diesel Engine |
Nominated Power/RPM |
kW/r/min |
107/2200 |
|
|
Nominated Working Condition Fuel Oil Consumption Rate |
g/kW·h |
≤223 |
||
Both Single and Rear Double wheel are all Available For 1504 Tractor:
| Why choose us? |
1. More than 500 workers.
2. With the occupying area of 2500 square meters.
3. More than 10 years experiences in the industry of construction machine and agricutural machine.
4. Competitive price and high quality.
5. One hour reaches Qingdao port.
6. All the inquiries will be replied within 12 hours
