Hot sales 20HP-130HP agriculture tractor
The advantage of 20-130HP agriculture tractor
| 1 |
Equipped with famous brand engine showing advanced capacity, low fuel consumption and high economic efficiency. |
| 2 | Reasonable distribution of speed, high efficiency in both farm working and transportation. |
| 3 | 150L enlarge fuel tank, long working time. |
| 4 | Double cylinder strong take-up device, with height limit, strong lift force, reliable and high efficiency. |
| 5 | Installed famous brand clutch, optional Germany LUK brand clutch. |
| 6 | Optional install rotary tiller, Three share plough, fininshing mover, log splitter, wood chipper, post hole digger, slasher, disc plough and disc harrow. |
| 7 | Optional double speed PTO( Power Take Off): 540/1000,760/1000r/min showing high working effiency. |
| 8 | Optional PTO shaft of 6 spline or 8 spline, adaptable for agricultural equipment of all over the world. |
| 9 | Stremlined appearance design, beautiful and generous. |
| 10 | Optional luxury closed drivers cabin, equipped air-conditioner, CD player, radio, adjustable soft seat, luxury inner decorations etc.. |
| Model | JT404 | JT454 | JT484 | JT504 | JT554 | ||
| Type | 40HP/4WD | 45HP/4WD | 48HP/4WD | 50HP/4WD | 55HP/4WD | ||
| Dimmensions of Tractor(mm) | Length | 3550 | |||||
| Width | 1660 | ||||||
| Height | 1550 | ||||||
| Tread | Front Wheel | 1300 | |||||
| Rear Wheel | 1300 | ||||||
| Wheel Base | 1980 | ||||||
| Min Ground Clearance | 300 | 350 | |||||
| Structure Weight(kg) | 1710 | ||||||
| Rated traction force(kn) | 9.7~12.8 | ||||||
| Engine | Model | XC490/JD490 | XC495/JD495 | XC498 | JD4100 | JD4102 | |
| Type | vertical, 4-cylinder, water cooled and 4-stokes | ||||||
| Rated Power | 29.4KW ~ 34.34KW | ||||||
| Rated Speed | 2300 / 2400 rpm | ||||||
| Fuel | Diesel | ||||||
| Tyre | Front Wheel | 7.50-16 | |||||
| Rear Wheel | 11.2-28 | ||||||
| Transmission Gear Box | 8+2 Shift | ||||||
| Clutch | Dry Single-stage or Dual-stage Clutch | ||||||
| Steering | Hydraulic Steering | ||||||
| Hydraulic Gear Pump | Two Hydraulic Pumps | ||||||
| Air Brakes | Available for Trailer | ||||||
| Suspension Type | Post positioned 3-point Hitch | ||||||
| PTO Type | Postpositioned, 6 teeth, Dual Speed PTO 540/1000 | ||||||
| KING TECH tractor brief introduction: | |
| 1 | Farm tractor 90HP, 4WD or 2WD |
| 2 | YTR4108T51A diesel engine |
| 3 | Dual clutch |
| 4 | Double PTO |
| 5 | Hydraulic steering |
| 6 | 16F+8R shuttle shift |
| 7 | Leave Hydraulic 3-point links Suspension |
| 8 | Optional: |
| Air conditioning cab | |
| Cab with fan | |
| Muti-way valve | |
| Low beam with movable arm | |
| Air break, | |
| Load bucket | |
| 4 in 1 Bucket | |
| Shuttle gear shift 8F+8R | |
| Creeper gear 16F+8R | |
| Creeper shift | |
| Front/Rear Ballas | |
| Paddy wheel | |
The Main Specification of 110hp to 130hp tractor | |||||
Tractor Model |
1104 |
1204 |
1254 |
1304 |
|
General Specification |
Driver Type |
4×4 |
4×4 |
4×4 |
4×4 |
|
Length×width×Height(mm) |
5015×2335×2970 |
5015×2335×2970 |
5015×2335×2970 |
5015×2335×2970 |
|
Traction force(KN) |
26 |
27 |
29 |
32 |
|
Steering |
hydraulic |
hydraulic |
hydraulic |
hydraulic |
|
Wheel base(mm) |
2688.5 |
2688.5 |
2688.5 |
2688.5 |
|
Front wheel tread(mm) |
1672-2003(1760) |
1672-2003(1760) |
1822-2153(1910) |
1822-2153(1910) |
|
Rear wheel tread(mm) |
1662-2262(1862) |
1662-2262(1862) |
1662-2262(1862) |
1662-2262(1862) |
|
P.T.O.Max.Power(Kw) |
71.25 |
71.25 |
81.7 |
81.7 |
|
Ground clearance(mm) |
465 |
465 |
465 |
465 |
Engine |
Type |
|
LR6108T1 |
|
LRC6110T52 |
|
Bore×Stroke(mm) |
108×125 |
108×125 |
110×135 |
110×135 |
|
Rated revolution (r/min) |
2300 |
2300 |
2300 |
2300 |
|
Max.torque(n.m) |
≥282 |
≥340 |
≥350 |
≥370 |
|
Speed of Max.torque r.p.m. |
1700-1800 |
1700-1800 |
1600-1800 |
1600-1800 |
Transmission |
Clutch |
Dual-stage clutch |
|||
|
Gear box |
12F+4R |
|||
Working device |
Lifter tilling depth control |
Height adjustable, floating control |
|||
|
Max.lifting capacity(KN) |
≥28 |
|||
|
Suspension type |
Class 2 3-Point hitch |
|||
|
Speed of P.T.O.(r/min) |
stardard:760/1000;optional:540/760,540/1000 |
|||
Notice:All above parameters are subject to change without notice because of rapid development of products. | |||||
Packaging Details:Packed in iron frame or as you needed
Weifang Jintai Power Machinery Co., Ltd. is specializing in generator sets, construction machinery and agricultural equipments. The generator output power from 5KVA to 2000KVA. The construction machinery includes wheel loader and dumper etc. The agricultural machinery include tractor, wood chipper, trailer, plough etc. We keep diverse products according to customers and market demand. Our engineer also can design it according to your special demand. All of products are produced in according with ISO 9001 quality management system and are rigorous tested before delivery.
We also offer after-sale service to our customer. We offer spare parts in free within the warranty and help you to install it.
1. Are you a manufacturer? Which products can you supply?
A: Yes, we are a manufacturer.
B: We specizlize in tractor from 15hp to 110hp.
Except for tractor we also produce generators and dumper.
2. Can you supply spare parts?
A: Yes, we supply spare parts, if within the warranty, we can offer spare parts free.
B: Warranty: 1 year
3. What is your MOQ? The delivery date?
A: MOQ: 1SET
B: Delivery date: if below 20sets, about 15days after we recieve the deposit, if more than 50sets about 1months.
4. Can you supply tractor according to our demand?
A: Yes
B: You can visit our company and we talk together about your new specific demand. Of course your engineer can send drawings to us.
5. How can i contact with you?
Trade manager: jintaipower
Wechat: lindamachine
Skype: lindamachine
QQ: 1521993639
Tel: +86 536 8278715
Mobile: 86 152 6466 8102
I am on line every day, you can contact with me at any time.
