Highlight of Everun ER15 log loader:
Fully Hydraulic Driving
CE,TUV Certificate
Euroiii Engine
Chinese factory
New cabin something like JCB style,the space is 1.2*1.36m
All loaders are designed under European customers' suggestion as market need
we have spare parts warehouse in Europe
Specifications of ER15 mini wheel loader from Qingdao Everun Machinery Co.,Ltd
Qingdao Everun Brand ER15 Mini Wheel Loader for Europe |
Standard Equipments: |
Standard Bucket, Luxury Cabin, Euroiii Engine, E-Mark Seat, Adjustable Steering Wheel,130W Heater, 220 V Engine Heater, Lock for Lifting and Steering Cylinder, Backward Imagine, Tipping Cabin, Hydraulic Joystick, Disc-Brake, Quick Hitch, 12-16.5 Tyre Hydraulic-pressure Check System, Blinking Lamp without Key, and Easy-damaged Spare Parts. |
Optional Equipments: |
Electric Joystick, Floating Function, E4 Lamp, Extra Hydraulic Line, LED Light, Varta Anti-free Battery,14-17.5 Tyre, 31.5 *15-15 Tyre, Tyre Chain |
Attachments: |
Pallet Forks,Grass Forks,Grapple bucket,Europe Grapple forks,Wooden Forks,Adjustable Pallet Forks,Snow Bucket,Snow Blade,Hydraulic Snow Blade,Snow Blower,4 In 1 Bucket,Drum Folder,Barrel Clamp,Mixer Bucket,Sweeper,Sender Spreader,Grapple Forklift,Mimi Digger,Auger,Snow Bucket with Wings,Plain Bucket. |
1.0 Engine Details |
(1) Model: Xinchai 498BT (Euroiii and EPA Approved) |
(2) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine |
(3) Rated Power: 37KW |
(4) Rated Speed: 2400 r/min (rpm) |
(5) Fuel Consumption ratio in standard working condition: 230g /kw. H |
2.0 Transmission System |
(1) Type: Fixed-spindle Power shift |
(2) Shift gear control oil pressure: 1.2~1.5MPa |
(3) Rated input speed: 2500 (rpm) |
3.0 Bucket |
(1) Bucket Capacity: 0.75 m3 (2) Bucket width: 1800mm |
(3) Bucket type: Heavy-duty bolt on teeth |
(4) Rated Load: 1500kg |
(5) Operating Weight: 3600kg |
4.0 Overall Dimensions |
(1) Overall Length (Bucket on ground position): 5300mm |
(2) Overall Height |
(3) Ground to Cab Top: 2750mm |
(4) Dumping Height: 2700mm |
(5) Min. Base to the Ground: 260mm |
(6) Overall Width: 1800mm |
5.0 Operating Specifications |
(1) Steering System: Articulated Frame with hydraulic power steering |
(2) Min Turning Radius: 4500mm |
(3) Driving System: Hydraulic converter |
6.0 Brake System |
(1) Service Brake: Four Wheel Hydraulic spread-shoed brake |
(2) Parking Brake: Hand operated |
7.0 Tyre: 12-1600/12-16.5/14-17.5/31-15.5-15 Agriculture Tyres |
8.0 Package:1 unit in 20GP,3 units in 40HQ. |
9.0Delivery time:20days after 20%-30% down payment |
10.0 Warranty:1 year |
Packaging Details: | 3 units in 40HQ container |
Delivery Detail: | 20-25 days after receiving the deposit |
Payments:
·Delivery time:20-25 days after deposit.
·Payment term: T/T 30% in advance
·Packing: 3 units in 40HQ container.
·Warranty time:one year
·Minimum order quantity:1 units
We are specialized in mini wheel loaders and agricultural machines as a manufacturer and exporter in China, all of our products are CE approved. We have many customers in European and American countries, now you can find our machines works in almost 30 countries.
