Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission

Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission photo-1
Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission photo-2
Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission photo-3
Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission photo-4
Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission photo-5
Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission photo-6
US$ 8,700 - 9,300 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
EVERUN
Model Number:
ER08
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Brand Name EVERUN
Model Number ER08
Condition New
After-sales Service Provided Overseas service center available

Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission



===============================================
Highlight of Everun Compact Wheel Loader
Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission
 Torque Converter Transmission System
CE Certificated, All Of Everun Loader Are Produced Under the Rule of CE.
Euro3 engine options
Large Cabin ,Nice View , Luxury interior
More Than 30 Durable,Safe and Effective Attachments Suitable For Everun
   Loader

.  Easy to Drive.All of Everun Loader Can Be Equipped With Quick
   Hitch, Joystick etc.
.  China Factory Directly Sale.High Quality with Reasonable Price


Details of Everun Compact Wheel Loader

Everun New Style ER08 Mini Wheel Loader With Hydraulic TransmissionEverun New Style ER08 Mini Wheel Loader With Hydraulic Transmission



Standard Equipments

Hydrostatic Driving System, 3 Cylinder Engine, Standard Bucket, Luxury Cabin Interior Similar to JCB, E-mark Seat, Adjustable Steering Wheel, Lock For Lifting and Steering Cylinder, Mechanical Joystick, Floating Function, Easy-damaged Spare Parts.

  Optional Attachments
 Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission




Specifications Of Er08 Front End Loader



1.0 Engine Details
(1) Model:Changchai 390
(2) Rated Power: 20 KW
(3) Rated Speed: 2200 r/min (rpm)
(4) Max. Torque: 90/1800N.m/min
(5) Fuel Consumption ratio in standard working condition: 252g /kw. H

2.0 Operating Specifications:
(1) Bucket Capacity: 0.48m3
(2) Loading Capacity: 800KG
(3) Operation Weight: 2000KG
(4) Lifting Time: ≤8.0s
(5) Driving Speed: 0-12km/h
(6) Min. Turning Radius: 1989mm
(7) Max. Turning Angle: ±38°

3.0 Overall Dimensions
(1) Overall Length (Bucket on ground position): 4600mm
(2) Overall Width: 1420mm
(3) Overall Height: 2500mm
(4) Dumping Height: 2000mm
(5) Dumping Reach:1100mm
(6) Min. Ground Clearance: 240mm
(7) Wheel Base: 2170mm

4.0 Brake System
(1) Service Brake: Four Wheel Hydraulic spread-shoed brake
(2) Parking Brake: Hand operated

5.0 Tyre : 750-16 tyre


Packaging &Shipping:

.Delivery time:15 days after getting down payment

·Payment term: T/T 30% in advance

·Packing: 3 units in 40HQ container. Loader will be fixed by triangle
               wood and 10mm wire

·Warranty time:one year

·Minimum order quantity:1 unit

Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission


Company Introduction:

Qingdao Everun Machinery Co.,Ltd is Specialized In Mini Wheel Loaders &Agricultural Machines as a Munufacturer &Exporter in China. All or our Products Are CE &EPA approved. Now We are Specializing In Producing &exporting of Wheel Loader From 0.6Ton --5Ton.
Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission

We set up Everun Europe Company with technical training system, spare parts warehouse and other support...
Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission
Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission

Now "Everun " Is Working For More Than 30 Countries and Customers All of the World Such As: Finland, Denmark ,Poland , Norway, Germany, Sweden, Switzerland,Portugal, New Zealand, America etc.
Everun New Style ER08 Mini Wheel Loader With Hydraulic Transmission

Welcome To visit our website at  or visit our factory located in Shandong . If you have further quesiton ,Please do not hesitate to contact at jiessie at
