Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
2WD
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BOTON 50hp 2wd Farming Tractor Double Disc Luk Clutch Seat Can be AdjustedNegotiableMOQ: 1 Set -
BOTON 45hp 4wd Tarctor Differential Lock Shock Absorption SeatNegotiableMOQ: 1 Set
-
BOTON 45hp 2wd Tarctor Spraying WiperNegotiableMOQ: 1 Set
-
BOTON 45hp 2wd Tarctor With Japan NSK BearingNegotiableMOQ: 1 Set
-
60HP BOTON FARM TRACTOR CABS WITH KOHLER ENGINE AND GERMANY LUK CLUTCHNegotiableMOQ: 1 Set
Condition
New
Type
Wheel Tractor
By wheel
2WD
Usage
Farm Tractor
Drive Type
Gear Drive
Power(W)
33075
Certificate
EEC
Brand Name
BOTON
Model Number
BTB450-02
Place of Origin
Henan, China
After-sales Service Provided
Engineers available to service machinery overseas
| Technical Specification | |||||||
| BOTON TRACTOR MODEL | BTB450-01/02 | BTB454-01/02 | BTB500-01/02 | BTB504-01/02 | BTB554-02 | BTB600-01/02 | BTB604-01/02 |
| Drive type | 4*2 | 4*4 | 4*2 | 4*4 | 4*4 | 4*2 | 4*4 |
| GENERAL SPECIFICATION | |||||||
| Length×Width×Heigh (mm) | 3700*1615 *2200 | 3700*1615 *2216 | 3700*1645 *2230 | 3700*1645 *2250 | 3700*1645 *2065 | 3700*1645 *2080 | 3755*1645 *2065 |
| Constructional Weight (KN) | 1610 | 1900 | 1665 | 1900 | 2000 | 1765 | 2000 |
| Ttraction force (KN) | 10 | 10.5 | 10.7 | 11.7 | 12.8 | 12.8 | 12.8 |
| Steering | Hydraulic | ||||||
| Wheel base (mm) | 1200-1500 | 1955 | 1940 | 1955 | 2010 | 1955 | 2010 |
| Front wheel tread (mm) | 1320-1620 | 1250 | 1330-1630 | 1250 | 1250 | 1330-1630 | 1250 |
| Rear wheel tread (mm) | 1300-1600 | 1300-1600 | 1300-1600 |
1300-1600 | 1300-1600 | 1300-600 |
1300-1600 |
| P.T.O Max.power (Kw) | 28.1 | 28.1 | 31.5/32.5 | 31.5/32.5 | 35.6 | 35.6 | 37.5 |
| Ground clearance (mm) | 380 | 300 | 400 | 300 | 300 | 400 | 300 |
| ENGINE | |||||||
| Type | 4L68 | 4L68 | 4G33T | 4G33T | 4G33T | 4L88 | 4L88 |
| Bore*Stroke (mm) | 95*100 | 95*100 | 95*115 | 95*115 | 105*117 | 95*100 | 95*100 |
| Rated revolution (r/min) | 2400 | 2400 | 2400 | 2400 | 2400 | 2300 | 2300 |
| Max.torque (n.m) | ≥155.4 | ≥155.4 | ≥173 | ≥173 | ≥190.2 | ≥216.1 | ≥216.1 |
| Speed of Max.torque r.p.m | ≤1800 | ≤1800 | ≤1800 | ≤1800 | ≤1800 | ≤1725 | ≤1725 |
| TRANSMISSION | |||||||
| Clutch | Often-combination,Dual-stage clutch,Dry,10 inches | ||||||
| Gear box | 12F+4R | ||||||
| WORKING DEVICE | |||||||
| Lifter tilling depth control | Forced buned | ||||||
| Max.lifting capacity (KN) | 7.4 | 7.4 | 8.3 | 8.3 | 9.1 | 9.9 | 9.9 |
| Suspension type | Class 1 3-point hitch | ||||||
| Speed of P.T.O.(r/min) | Standard:540/720;optional:540/1000,720/1000 | ||||||
