DongFeng Design Small Gasoline Engine KG160

Name: DongFeng Design Small Gasoline Engine KG160
Brand: SUMOKAMA
SKU: 140760908
Availability: InStock

Changzhou Yarmax Power Co., Ltd.

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Usage:

Other

Fuel:

Gasoline

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Usage Other

Fuel Gasoline

Stroke 4 Stroke

Cylinder Single Cylinder

Cold Style Other, Air-cooled

Start Other, kick or electric start

Place of Origin Jiangsu, China

Brand Name SUMOKAMA

Model Number KG160

Dimension(L*W*H) 415*380*380

Weight 15/17

Certification CE,ISO

Warranty 1 Year or 1000 Hours Warraty

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1)OHV,Cylinder,Four-stroke,Air cooled
2)Electric start/Hand starting
3)Low fuel consumption(g/kw.h):395

Gasoline Engine KG160

Model	KG160
Engine type	4-stroke 25 single-cylinder with air-cooled
Bore*stroke	68mm*45mm
Displacement	163ml
Compression ratio	8.5:1
Max power output	4.0kw/3600rpm
Recommded power using	3.4kw/3600rpm
Max torque	10N.m/2500rpm
Lgnition system	Non-contact transistorized ignition(TCI)
Start model	Recoil and hand-operated/electric
Air cleaner	Semi-dry oil bath type
Fuel tank capacity	3.6L
Fuel consumption	395g/kw.h
Engine oil capacity	0.6L
Dimension(LWH mm)	320385336
Dry weight	15kg/17kg
Carton dimension(LWH mm)	415380380
QTY 20GP/40GP/40HQ	504/1008/1176
