Help CenterDiesel Engine (KM178F)
US$ 200 - 800
MOQ: 240 Pieces
Key Specifications
Get Latest Price
Usage:
Other, Agriculture
Fuel:
Diesel
Stroke:
4 Stroke
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Usage
Other, Agriculture
Fuel
Diesel
Stroke
4 Stroke
Cylinder
Single Cylinder
Cold Style
Other, Air-cooled
Start
Electric Start
Place of Origin
Jiangsu, China
Brand Name
Sumokama
Model Number
km178FA
Specifications
Diesel Engine (KM178F)Both electrical start and hand start
Product Description
1 .Low fuel consumption, low noise, low pollution, high efficiency and environmental protection.
2. Our products has the strict test system, the voltage and frequency is stability
3. FOB price, high quality and good service.
4. Diverse styles and humanized choice, and can be widely used in the family supermarkets hotels, pleases such as the temporary outage.
| Engine type | Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine | |
| Bore*stroke[mm(in)] | 78x62(3.07x2.44) | |
| Dispiacement[ml(cu. in)] | 296(18.06) | |
| Engine speed(rpm) | 1500/1800 | |
| Compression ratio | 20: 1 | |
| Rated output power[kW(HP)/rpm] | 3.7(5.03)/3000, 4.0(5.44)/3600 | |
| Rotation direction (view from flywheel) | Clockwise | |
| Fuel | 0#or-10#light diesel oil | |
| Fuel tank volume[L(gal. )] | 3.5(0.77) | |
| Fuel consumption rate[g(ml)/kW. h] | 1500rpm: 276(329), 1800rpm: 285(339) | |
| Lubrication oil volume[L(gal. )] | 1.1(0.24) | |
| Power-Take-Off | Crankshaft or Camshaft(Camshaft PTO rpm is 1/2) | |
| Starting system | Recoil | |
| Overall dimension(L*W*H)[mm(in)] | 383× 421× 450(15.08× 16.57× 17.72) | |
| Dry weight[kg(ibs. )] | 33(72.6) | |
| Lube brand | SEA10W30(above CC grade |
