Home > Products > Diesel Engine > Air Cooled Diesel Engine (14hp)
Air Cooled Diesel Engine (14hp)
- SHANGHAI CHINA
- T/T D/P D/A
You May Like
Product Details
| Usage | Automobile | Fuel | Diesel | |
| Stroke | 4 Stroke | Cylinder | Single Cylinder | |
| Cold Style | Other, Air-cooled | Start | Electric Start | |
| Place of Origin | Jiangsu, China | Brand Name | Sumokama | |
| Model Number | YM188F-B |
Product Description
Specifications
1)Low-oil pressure2)Full perimeter safety frame
3)Large fuel tank 5.5L
4)Wheel kit
5)14HP output
Model | YM188F-B(14hp) | |
Type | Single-cylinder,vertical,4-stroke air-cooled diesel engine | |
Combustion system | Direct injection | |
Bore X Stroke(mm) | 88×75 | |
Displacement(L) | 0.456 | |
Engine Speed(rpm) | 3000 | 3600 |
Max.output | 7.8Kw/10.6Hp | 8.6Kw/11.7Hp |
Rated output | 7.5Kw/10.2Hp | 8.3Kw/11.3Hp |
Fule | 0# or -10# light diesel fuel | |
Fule oil tank volume(L) | 5.5 | |
Lubricatiom oil volume(L) | 1.65 | |
Fule consumption rate(g/kw.h) | ≤275 | ≤295 |
Valve clearance (mm) | 0.10-0.15 | |
PTO Model | Crankshaft | |
Starting system | Recoil or Electric (E) | |
PTO rotation direction | counter-clockwise | |
Battery | Optional | |
Dimension(mm) | 420×440×495 | |
Net weight(kg) | ≤53 | |
20FT | 220pcs | |
We reserve the right to change specifications without notice | ||
