Air Cooled Diesel Engine KM186F

Name: Air Cooled Diesel Engine KM186F
Brand: Sumokama
SKU: 140759956

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Usage:

Automobile

Fuel:

Diesel

Stroke:

4 Stroke

Changzhou Yarmax Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI CHINA

Delivery Detail:

Delivery time depends on order quantity.

Usage Automobile

Fuel Diesel

Stroke 4 Stroke

Cylinder Single Cylinder

Cold Style Other, Air-cooled

Start Electric Start

Place of Origin Jiangsu, China

Brand Name Sumokama

Model Number KM186F

Specifications

1. Powered by 4-stroke engine
2. Circuit breaker protects overload operation
3. Large fuel tank ensures long time work

Model	KM186F
Type	Single-cylinder,vertical,4-stroke air-cooled diesel engine
Combustion system	Direct lnjection
Bore X Stroke(mm)	86x70
Displacement(cc)	406
Engine Speed(rpm)	3000	3600
Max.output(kw)	6	6.3
Rated output(kw)	5.7	6.0
Fule	0# or -10# light diesel fuel
Fule oil tank volume(L)	5.5
Lubricatiom oil volume(L)	1.65
Fule oil consumption rate(g/kw.h)	275.1	281.5
Valve clearance (mm)	0.10-0.15
PTO Model	Crankshaft or Camshaft
Starting system	Recoil or Electric
PTO rotation direction	It is clockwise as viewing from the flywheel end
Battery	Optional
Dimension(mm)	420x440x495
Net weight(kg)	≤47
20FT	220
We reserve the right to change specifications without notice
