Hydraulic truck crane
Truck crane 10 Ton
Brake:Vacuum booster
Loading weight:10000kg
Height:2650mm
Small truck crane 10ton
Product model |
NEW10T |
Total mass kg |
9640+500 |
Overall dimension mm |
8950*2500*3040 |
Rated elevating capacity kg |
10000 |
Rated Lifting torque kn*m |
240 |
Max. Lifting Height m |
26.5 |
Main hook single load kg |
1500 |
Main hook single elevating speed m/min |
50 |
Auxiliary hook single load kg |
500 |
Auxiliary hook single elevating speed m/min |
100 |
Engine model |
YANGCHAI 4102(YZ4DA7-30) |
Derailleur model |
LG5-38 With high and low speed auxiliary box |
Tires |
8.25-16 with spare tires |
Braking form |
Break air brake |
Steering form |
Hydraulic power steering |
Crane jib structure |
Category five hexagon box-type, hydro cylinder telescopic boom |
Main Lifting Mechanism |
Category two planet wheel with a brake inside |
Auxiliary Lifting Mechanism |
Category one gear brake motor |
Swing Bearing |
GB Φ1000 Tooth, material 50Mn intermediate frequency |
Vertical hydraulic leg |
Double-acting engineering oil cylinder |
Horizontal hydraulic leg |
Double-acting engineering oil cylinder |
Platform |
Anti-skidding and big |
Protective Screening |
Two-way |
Night light |
3 lamps control |
Dynamic Motor |
GB 11KW-4 pole |
Crane Cab |
Tailor-made |
The central axially symmetrical |
Four oil ways |
Crane Start |
Tailor-made |
Throttle |
Hydraulic |
Warning Horn |
Mono snail |
Pressure gage and switch |
Shockproof component |
Power Takeoff |
Driving indoor operation zip type |
Hydraulic Oil Tank |
Turntable rear mounted, counter weight combined type, special four-layer filters |
Load displayer/ Lift height limiting stopper |
Optional |
Advantages to work with us:
1)A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage inviorenment.
3)Unparalleled after sales service
Export Market Distribution:
| Market | Revenue(Previous Year) | Total Revenue (%) |
|---|---|---|
| South America | confidential | 2.42 |
| Southeast Asia | confidential | 2.61 |
| Africa | confidential | 1.49 |
| Oceania | confidential | 0.12 |
| Mid East | confidential | 0.12 |
| Eastern Asia | confidential | 0.1 |
| Domestic Market | confidential | 93.14 |
Production Flow:
