30hp 4WD NEW304 with all attachments mini tractor
*4*4 wheel drive
*Dual clutch
*Cabin with warmer or air condition
1. 30hp, 4wd
2. dual-stage clutch
3. hydraulic steering
4. gearshift 8F+2R or 16F+8R(optional) or 8F+8R(optional)
5. tractor implements are available
We have farm tractors cover 25-110hp, with all kinds of attached implements. Here is the detailed information for 304 farm tractors,
| Model | NEW304 | ||||||
| Type | 4WD Wheeled Type | ||||||
Dimensions of Tractor (mm) | Length (to front ballast) | 3030 | |||||
| Width | 1470 | ||||||
| Height (to the exhaust vent) | 1900 | ||||||
| Tread | Front Wheel | 1215 Fixed or 1150~1215 Adjusted | |||||
| Rear Wheel | 1300 Fixed or 1300~1350 Adjusted | ||||||
| Axle Base | 1710 | ||||||
| Min.Ground Clearance | 347.5 | ||||||
| Structure weight (kg) | 1130 | ||||||
| Ballast weight (kg) | Front ballast | 56 | |||||
| Rear ballast | 112 | ||||||
| Rated traction force (kg) | 663 | ||||||
| Engine | Model | 390/485 | |||||
| Type | Vertical,3-Cylinder,Water Cooled and 4-stroke | ||||||
| Rated Power(kw) | 22 | ||||||
| Rated speed (r/min) | 2400 | ||||||
| Fuel | Diesel | ||||||
| Tyre | Front Wheel | 6.00-14 | |||||
| Rear Wheel | 9.5-24 | ||||||
| Clutch | Dual-stage clutch | ||||||
| Steering | power steering | ||||||
| Transmission Type | 8+2 or 8+8 with shuttle gearshift or 16+4 with creeper shift | ||||||
| Suspension Type | 3-point links | ||||||
| PTO | Type and Rev | Semi-independent Type 540/1000 | |||||
| Spline Size | F35 Rectangle Spline with 6 teeth | ||||||
Advantages to work with us:
1)A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage inviorenment.
3)Unparalleled after sales service
Our Main Products Covers
1)Wheel loader D25,ZL08.ZL10,ZL12,ZL16,915,ZL20,ZL30 and ZL50.
2)Site Dumper 2ton, self loading dumper 2ton, 3 ton hydraulic dumper,3 ton dumper with side dumping type,5 ton dumpers.
3) Mini Tractors with different attachments from 25HP to 110HP.
