Help Center2016 Hot ZL16 1.6ton CE Shovel Wheel Loader
Related Products
-
2016 Hot 1.2ton ZL12 Hot Sale Mini Shovel LoaderUS$ 8,688 - 9,017MOQ: 1 Unit -
2016 Hot China 1.2ton ZL12 Mini Wheel LoaderUS$ 8,688 - 9,017MOQ: 1 Unit
-
1.2ton ZL12 Hot Sale CE Mini Wheel LoaderUS$ 8,688 - 9,017MOQ: 1 Unit
-
Multi-functional CE D25 Mini LoaderUS$ 13,279 - 13,935MOQ: 1 Unit
-
ZL08 0.8ton CE Mini Wheel LoaderUS$ 5,738 - 6,558MOQ: 1 Unit
1.A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage inviorenment.
ZL16 1.6ton CE shovel wheel loader
loader 1.6ton ZL16
1.Engine:weichai4102
2.Power:47KW
3.Bucket Capacity:1.0m3
4.Rated Load:1600kg
Standard packing
Our Main Products Covers
1)Wheel loader D25,ZL08.ZL10,ZL12,ZL16,915,ZL20,ZL30 and ZL50.
2)Site Dumper 2ton, self loading dumper 2ton, 3 ton hydraulic dumper,3 ton dumper with side dumping type,5 ton dumpers.
3) Mini Tractors with different attachments from 25HP to 100HP.
Contact:Daisy Liu
Tel:+86 15169643109
Skype:daisy19871227
uyaos
Overall Dimension | ||||
1 |
Length(with bucket on ground) |
5500(mm) |
||
2 |
Bucket width |
1910(mm) |
||
3 |
Height(To the top of the cab) |
2700(mm) |
||
4 |
Wheel base |
2150(mm) |
||
5 |
Tread |
1500(mm) |
||
6 |
Min. ground clearance |
342(mm) |
||
Main Technical Specification | ||||
1 |
Rated load |
1600(Kg) |
||
2 |
Operating weight |
4300KG |
||
3 |
Rated bucket capacity |
1.0(CBM) |
||
4 |
Max. breakout force |
45KN |
||
5 |
Max. dump clearance |
2850 (mm) |
||
6 |
Dump reach |
960(mm) |
||
7 |
Dump angle at any position |
≤40 |
||
8 |
Digging depth(with bucket bottom horizontal) |
146(mm) |
||
9 |
9 Max. turning radius |
|
||
|
(1) Outside of bucket |
4850(mm) |
||
(2) Outside of rear wheel |
4675(mm) |
|||
10 |
Pivot angle frame |
38+ |
||
11 |
Oscillating angle of rear axle + |
±11° |
||
12 |
Lifting time of bucket |
≤5.9(sec.) |
||
13 |
Lowering time of bucket |
≤2.8(sec.) |
||
14 |
Dumping time |
≤2.0(sec.) |
||
15 |
Traveling speed(Km/h) 2 forward and 2 reverse |
|
||
|
(1) 1st gear forward |
10.00 |
||
|
(2) 2nd gear forward |
24.00 |
||
|
(3) 1st gear reverse |
10.00 |
||
|
(3) 2nd gear reverse |
24 |
||
Remarks:
1) Payment terms: 30% T/T deposit,balance before shipment.
2) Delivery date: 25-30 days after we receive the deposit
3) Quotation valid date: within 30 days
4)The MOQ:One Set
