1.A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage inviorenment.
Multifunction mini wheel loader D25 wheel shovel loader
Our Main Products Covers
1)Wheel loader D25,ZL08.ZL10,ZL12,ZL16,915,ZL20,ZL30 and ZL50.ZL60.
2)Site Dumper 2ton, self loading dumper 2ton, 3 ton hydraulic dumper,3 ton dumper with side dumping type,5 ton dumpers.
3) Mini Tractors with different attachments from 25HP to 100HP.
Engine |
|
Model | PERKINS 403D-11 |
Rated power | 18.5kw(24.8BHP) |
Rated speed | 2800rpm |
Maximum torque | 67Nm |
The ratio of fuel consumption | 252g/kwhr |
Dimensions |
|
Body length | 3690mm |
Body width(reverse tyre) | 1050mm/970mm |
Body height | 2300mm |
Minimum ground clearance | 200mm |
Maximum dumping height | 2000mm |
Dumping reach | 600mm |
Wheel base | 1340mm |
Performance parameters of the machine | |
Bucket | 0.4m3 |
Tipping load in shovel,vehicle straight raight straight798kg | 798kg |
Tipping load in shovel,vehicle at 68° | 498kg |
Operating weight | 1470kg |
The sum of the work device | 8s |
Driving speed | 0-12km/h |
Minimum turning-circle radius |
|
Outside face of bucket | 1989mm |
Outside face of tyre | 1469mm |
Tyre specifications | 27*8.5-15TL |
Maximum turning angle | ±68° |
Remarks:
1) Payment terms: 30% T/T deposit,balance before shipment.
2) Delivery date: 25-30 days after we receive the deposit
3) Quotation valid date: within 30 days
4)The MOQ:One Set
