Home > Products > dumper/dump truck > 2016 CE 5ton FCY50 hydraulic site mini tip truck
2016 CE 5ton FCY50 hydraulic site mini tip truck
- 100 Unit / Units per Month
- Qingdao
- T/T Credit Card
Product Details
Drive Wheel: | 4x4 | Capacity (Load): | 1 - 10t | Horsepower: | Other, 32HP-64HP |
Condition: | New | Transmission Type: | Automatic | Emission Standard: | Euro 3 |
Fuel Type: | Diesel | Engine Capacity: | 4 - 6L | Gross Vehicle Weight: | 3000 |
Place of Origin: | Shandong, China | Brand Name: | NEW.A | Model Number: | FCY50 |
Dimensions (L x W x H) (mm): | 4300x1920x2650mm |
Product Description
CE 5ton FCY50 hydraulic mini site tip truck
hydraulic truck with front dumper FCY50
Loading weight:5000kgs
Bucket capacity:2.0m3
Engine:Deutz engine optional
Loading weight:5000kgs
Bucket capacity:2.0m3
Engine:Deutz engine optional
Dumpers brief introduction:
As a low-volume, short-distance transport of bulk materials for small site dumpers, because of its easy operation, small turning radius can be used in a narrow environment, etc,. Dumpers are widely used in many different occasions, such as the construction industry, the factory floor, battlefield ,protecting road section, the municipal engineering, underground mines and so on.
1. more than 10 years production experience
2. own a super technical team, can finish some adjustment to adapt the using environment and the market
3. production capacity: 300 units/month
DUMPER | FCY-50 | |
Engine details | Model | Weichai 4102 |
Engine Type | In-line, water-cooled, 4 | |
Rated Power | 47kw | |
Rated Speed | 2200r/min | |
Hydraulic | Tipping and steering | |
Bucket | Bucket Capacity | 2.0m³ |
Rated Loading Weight | 5000kg | |
Operating Weight | 3050kg | |
Dimensions | Overall Length | 4300mm |
Overall Height | 2650mm | |
Overall Width | 1920mm | |
Wheel Base | 2000mm | |
Tread | 1580mm | |
Minimum turn radius | 4000mm | |
Tire | Front tire:20.5/70-16 | Rear Tire:20.5/70-16 |
Drive Type | 4*4 Wheel Drive |
Advantages to work with us:
1)A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage inviorenment.
3)Unparalleled after sales service
Remarks:
1) Payment terms: 30% T/T deposit,balance before shipment.
2) Delivery date: 25-30 days after we receive the deposit
3) Quotation valid date: within 30 days
4)The MOQ:One Set
Remarks:
1) Payment terms: 30% T/T deposit,balance before shipment.
2) Delivery date: 25-30 days after we receive the deposit
3) Quotation valid date: within 30 days
4)The MOQ:One Set
