1.A professional international sales team, which enable us to turn inquiries into final products and export them to numerous countries and regions without barriers;
2) A well managed quality control system to customize on clients requirements. We can design according to customers usage inviorenment.
WZ180 mini tractor backhoe loader
loader WZ180
1.Engine:Xichai4100
2.Power:49KW
3.Bucket Capacity:0.2-0.45m3
4.Rated Load:4500kg
Standard packing
Our Main Products Covers
1)Wheel loader D25,ZL08.ZL10,ZL12,ZL16,915,ZL20,ZL30 and ZL50.ZL60.
2)Site Dumper 2ton, self loading dumper 2ton, 3 ton hydraulic dumper,3 ton dumper with side dumping type,5 ton dumpers.
3) Mini Tractors with different attachments from 25HP to 100HP.
| BACKHOE LOADER: WZ180 | |
| Model: | WZ180 |
| Total operating weight: | 4500 KGS |
| Overall dimension: | 6800*1800*2700 mm |
| Front Wheel base: | 1400 mm |
| Rear Wheel base: | 1400 mm |
| Tread | 1695 mm |
| Mini Ground clearance | 240 mm |
| Loading Bucket capacity | 0.45 m3 |
| Backhoe bucket capacity | 0.20 m3 |
| Digging up capacity | 32 KN |
| Max.bucket discharge height | 2000 mm |
| Backhoe bucket height | 2400 mm |
| Max.Digging depth | 3000 mm |
| Bucket swing angle | 180° |
| Engine | XICHAI 4100 |
| Rated Power: | 49 kw |
| Max.travel speed: | 13 km/h |
| Mini lower speed | 6 km/h |
| Wheel Tire type: | 12-16.5 |
| Wheel pressure: | 0.22 Mpa |
| Steering system: | |
| Steering angle: | 35° |
| Min turning radius: | 5600 mm |
| Transmission system: | Hydraulic torque converter,Model 240 |
| Auto transmission | |
| Pressure of system | 20 MP |
| Flow | 138 L/min |
| Bucket lift time: | 4 s |
| Bucket lower time: | 1 s |
| Bucket discharge time: | 1 s |
| Hydraulic pilot controlling system: | Hydraulc Sensing Prior Controlling |
| Wheel drive: | 4 X 4 WD |
| Certificate: | with CE certificate |
| Shipment: | 2 units in one 40'HQ |
Remarks:
1) Payment terms: 30% T/T deposit,balance before shipment.
2) Delivery date: 25-30 days after we receive the deposit
3) Quotation valid date: within 30 days
4)The MOQ:One Set
