500cc 4*4 UTV(MC-170)

Model Number: MC-170

UTV-500 4x4 Features:

Packaging & Delivery
Packaging Detail 7LAYERS SHIPPING CARTON, WITH STRONG IRON FRAME ALL COMPLETE FINISHED PRODUCTION WHEN PACKING,WE DISASSEMBLE THE WHEELS,
Delivery Detail PRODUCTION TIME 20-25DAYS SINCE ADVANCE PAYMENT

.

With a liquid-cooled, 4-stroke engine.  The  4-stroke engine presents excellent power over a standard 250/300 class vehicle in a light weight, full-sized ATV while the liquid cooling provides excellent wear characteristics and thusly, longevity.  The UTV-300 has a 2-speed CVT automatic transmission with Hi / Lo / Neutral / Reverse as well as shaft drive at the front and rear wheels.  All of these features plus the Linhai name in quality means that with regular maintenance, this UTV will go for many years without the likelihood of needing major service.  If you take care of it, it should last for a very long time.

The gauges and controls are large and easy to read and use.  The roll cage is built stylish but tough (take a look) for heavy duty utility use but with the 2-Speed transmission and 2WD / 4WD, you can also get into sport mode and race around in the woods, mud or sand... and when it's time to 'get back to work' on the farm or ranch.

Description

DIMENSIONS
duct dimensions (mm): 3370×1280×1880mm
2.Wheelbase (mm): 2452mm
3.Wheel span (mm):  a) Fr: 1225mm   b) Re: 1215mm
4.Ground clearance(mm): 220MM

ENGINE(CFMOTOR)
5.Type: single cylinder,4-Stroke,Liquid-cooled
6.Bore*Stroke(mm): 87.5*82mm
7.Displacement: 493ml/24HP
8.Compression ratio:10.2:1
9.Starting: electric
10.Transmission:automatic clutch(R/N/H/L)
11.Drive type:shaft, 2WD/4WD/Differential
   Normal drive: Rear wheel drive

CAPACITIES
12.Fuel tank: 22.0L
14.Battery: 12V
15.Max speed: 75-84km/h

WEIGHT
16.Max load capacity: 300kg
   Net Weight: 697kg
   Gross Weight: 750kg

17. packing Size:
   40HQ  2970*1310*1230mm

18.Conveyance:
   Qty/40'HQ:8pcs

19. COLOR:
   Red,Orange,Blue, Black,Army green,Maple leef Camo, Army grenn Camo
Atv,Quad  go kart and Buggy .utv HS code:8703101100
