NEW 200W KIDS SCOOTER(MC-244)

  NEW 200W KIDS SCOOTER(MC-244)

Products Size.............................................     900mmX570mmX700mm
Motor Type ....................................................brushed DC , 200W/24V
Motor Max Loaded Amps...................................13.8A
Torque...........................................................0.89(N.m)
Max RPM........................................................2700±7.5%(rpm)
Controller Type...............................................Air cooled, non water -proof; brake shutoff, charger port
Battery..........................................................Lead-Acid Battery, 12V/ 5AH*2pcs
Charging Time..................................................6-8 hours
Battery Charger .........................................Input-100-240VAC,50/60Hz; Output-DC24V,0.6A
Special Features................................................Dismountable Handle bar
Turning angle....................................................28o
Transmission Ratio..............................................92/11
Seat Height........................................................500 mm
Wheel base Distance...........................................580 mm
Front & Rear Tire and Rim .............................12?×2.75
Maximum Carrying Capacity..................................42kgs
Mini Ground Clearance.........................................120mm
Maximum Speed.................................................Low speed:7km/h;  high speed:15km/h
Maximum Distance Range ..............................8km
Control System ...........................................handle bar control
Throttle Type....................................................turn control
Front & Rear Braking System................................Mechanical disc,left handle control
Drive System.....................................................Chian drive
Brake Distance...................................................≤2m(7km/h); ≤4m(15km/h)
Packing Size.......................................................960mmx280mmx550mm
N.W/G.W...........................................................21kgs/24kgs
