4 Stroke Gasoline Engine Small Engine

4 Stroke Gasoline Engine Small Engine thumbnail-1
4 Stroke Gasoline Engine Small Engine thumbnail-2
4 Stroke Gasoline Engine Small Engine thumbnail-3
4 Stroke Gasoline Engine Small Engine thumbnail-4
4 Stroke Gasoline Engine Small Engine photo-1
4 Stroke Gasoline Engine Small Engine photo-2
4 Stroke Gasoline Engine Small Engine photo-3
4 Stroke Gasoline Engine Small Engine photo-4
US$ 54 - 87 MOQ: 105 Units
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, used as power source for other machines
Fuel:
Gasoline
Contact Supplier Request Quote Chat Now
Chongqing Hongmei Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
CHONGQING SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Usage Other, used as power source for other machines
Fuel Gasoline
Stroke 4 Stroke
Cylinder Single Cylinder
Cold Style Other, Air-cooled
Start Kick Start
Place of Origin Chongqing, China
Brand Name HONGMEI
Model Number HM168FB
Dimension(L*W*H) 410*380*400
Weight 20KG
Certification CE ISO
Warranty 1year
After-sales Service Provided No overseas service provided

4 stroke gasoline engine small engine

Product Description
ENGINE TYPE
model  HM168FA HM168FB HM170F HM173 HM177 HM182 HM188 HM190F
power 5.5HP 6.5HP 7HP 8HP 9HP 11HP 13HP 16HP
max output(hp/rpm)  5.5/3600 6.5/3600 7/3600 8/3600 9/3600 11/3600 13/3600 16/3600
max torque(N.W/rpm) 4.5/2500 4.5/2500 4.5/2500 16.6/2500 18.5/2500 23.5/2500 26.5/2500 28.5/2500
bore*stroke(mm) 68*45 68*54 70*54 73*58 77*58 82*64 88*64 90*66
displacement(CC) 169ml 196ml 210ml 242ml 270ml 337ml 389ml 420ml
compression ration 8.5:1 8.5:1 8.5:1 8.2:1 8.2:1 8.2:1 8.0:1 7.8:1
start system  recoil  recoil recoil recoil recoil recoil recoil recoil
fuel tank capacity  3.6L 3.6L 3.6L 6L 6L 6.5L 6.5L 6.5L
oil capaticity  0.6L 0.6L 0.6L 1.1L 1.1L 1.1L 1.1L 1.1L
lubrication type Splashing
fuel consumption ≤374g/kw.h
noise(Away from 7 meters) 74db
dimension(L*W*H)mm 410*380*400 490*450*535
net weight (kg) 16KG 20KG 20KG 25KG 27KG 32KG 34KG 36KG

4 stroke gasoline engine small engine

6.5hp is the most popular and widely used engine model, our HM168FB is born with an attractive looking, high quality materials, high performance and well function, it seldom has problem under normal working condition even in serious conditions. This gasoline engine is widely used on constructional machinery, reaping machines, tilling machines, irrigation machines etc. We also provide 1/2 speed reduction for this model. Well warmly welcome distributors and friends from all over the world to cooperate with us.

 4 stroke gasoline engine small engine4 stroke gasoline engine small engine4 stroke gasoline engine small engine



Packaging & Shipping

PACKING   PLASTIC +CARTON +PLASTIC +WEAVE BELT

4 stroke gasoline engine small engine

Advantage

1.Low noise (less than 74db away from 7 meters )

2.Easy start

3.4 Stroke Motor

4.Saving fuel (<=374g/kw.h)

Certification

CE

4 stroke gasoline engine small engine

ISO

4 stroke gasoline engine small engine

workshop

4 stroke gasoline engine small engine

Company Information

Eatablisen in the year 1990,Chongqing Hongmei Technology Co.,Ltd is a high-ended agricultural machinery company which is specilised in R&D. manufacuring and marketing of general purpose power and agricultural machinery and started in this field since the year 2004.It started to apply for goverment allowance for agriculture machinery since the year 2008.

1) honor

Our company has passed ISO9001:2000 internatiioinal quality certification ,gained national"3C", certification ,"Chongqing famous product""Authentlcation and Marketing permission for agricultural machinery "for 13 models of products.

2) products widely accepted

We mainly specilise in manufacturing agricuture machinery such as gasoline engines water pumps gasoline generators power tillers harvesters .The products have been sold to over 20 countries all over the world until now

Chongqing Hongmei Technology Co.,Ltd looks forward to cooperating with you and creating a prosperous future.
