10 ton hydraulic vibratory roller in hot

Specifications

1.High reliability
2.Easy to operation
3.One year warranty
4.Flexible sttering
5.High effeciency

10 ton hydraulic vibratory roller in hot



1. Features



1.Power system: cummins B-series extra-pressure diesel engine,huge power man coeffciency ,suitable for the operating conditon above 4000 meters altitude.

2.Total hydraulic pressure,total drive, frequency and radiation conversion, articulated direction change, two stepless speed changes, advanced technology, blocking the oil supply to brake the vehicle,safe and reliable.

3.Streamline outline,circular windshield glass and curvy hood form a unique style.

4.Hydraulic pump and vibrating motors are of the 90 series made by the american manufacturer SAUER.

5.Equipped with padfoot or removal padfoot as option



2. Standard configuration



Engine : 6BT5.9

Cab : Air conditioner cab

Travelling and vibrating system : Adopt the products of SAUER or REXROT



3. Optional configuration



1. Degree of compaction random detector

2. padfoot or removal padfoot





4. Main Technical Parameters





Model		QLND210H
Operating mass	kg	10000
Static linear load	N/cm	285
vibration amplitude	mm	1.8/0.9
Vibration frequency	Hz	29/35
Centrifugal force	KN	240/120
Travel speed	km/h	12
Grade ability	%	35
Turning radius	mm	6500
Overall dimension	mm	5630x2260x3000
Vibration round with	mm	2100
Wheelbase	mm	3160
Ground clearance	mm	472
Diesel power	KW	110
Diesel model		6BT5.9



5. Application

  QLND210H

 Hydraulic vibratory roller is manufactured according to the international advanced technology

and by use of imported components from abroad.

 The machine is super heavy-scale mechanized construction.

 This machine is suitable for non-cohesive materials, such as graves, macadam,

macadam-aggregate mixtures and sandy soil etc.

 Also it can be a good effect compaction in cohesive material.

 Therefore the machine an ideal equipment for expressway,mining road, embankment, seaport and industrial sites.



6. Pictures



Details of  QLND210H





We offer low price products with highest performance cost ratio.
