Specifications
Famous engine YTODual-hydraulic output
Stable performance tractor
Farm tractor for sale philippines
QLN954 tractor:
Strong driving force and high quality!!
MAIN FEATURES:
1. Adopt Dongfanghong diesel engines. Better reliability, more back coefficient for torsion.
2. Clutch with independent operation double actions.
3. Gear-box shows 4X(2+1), namely 8 forwards, 4 returns, if choosing climbing shift, then 16 forwards,8 returns, shift in mesh;
4. Driving force output device with postposition, peaceful and stable transmission, stronger bear the weight of loading.
5. Adopt front-wheel turning with full liquid-pressure and independent oil way, turn agilely, reliably, power-saving;
6. Adopt static hydraulic tray-style arrester, stronger brake moment, reliable brake;
7. Adopt strong pressure lifter, independent oil supply, system performance reliable; multi-liquid output optional
8. The final driving is planet-gear style, smaller volume, bigger decelerating ratio;
9. Installed adjustable chair with elasticity and shock absorption, comfortable driving.
10. The whole tractor is beautiful, taste, modern, fashion

PRODUCTS:
Famous engine YTO
Dual-hydraulic output
Stable performance tractor
Farm tractor for sale philippines
Model | QLN954 |
Drive type | 4×4 |
Technical parameter | |
Dimension(L×W×H)(mm) | 4280×2085×2925 |
Wheel base (mm) | 2195 |
Wheel tread F/R (mm) | 1610/1620~2020 |
Adjust mothed of wheel tread | Level adjustment |
Min. ground clearance (mm) | 370 |
Ballast F/R (KG) | 220/(320,480,640) |
Tyre F/R | 11.2-24/16.9-34 |
Engine | |
Engine type | Vertical ;water cooled; 4-stroke; direct injection |
Manufacturer | YTO; Yuchai |
Volume of fuel tank (L) | 150 |
Rated power (kW) | 70 |
Rate oil consumption rate | ≤2.04 |
Transmission | |
Clutch | Single ,dry ,butterfly spring pressure ,independent ,dual stage |
Gear box | F16+R8 |
Speed of PTO (r/min) | 760/1000 |
Steering system | |
Steering system type | Hydraulic steering |
Working device | |
Model of suspension mechanism | Rear mounted; 3-point linkage, Category Ⅱ |
Tilling depth control type | Floating control |
Max. lifting force at suspension point 610 mm (kN) | 16.8 |
Hydraulic output valve | 2 group (multi-way valve) |
PTO shaft size | Φ38×8 or Φ35×6 or Φ34.67×21 |
PTO power(kW) | 59.5 |
QLN tractor have over 70 types tractor main in 6 series.Let me show you below:
1.30 series 250-354 (from 25hp-35hp 2/4wd)
2.40 series 400-554B (from 40hp-55hp 2/4wd)
3.55 series 550-654 (from 55hp-65hp 2/4wd)
4.80 series 700-854B (from 70hp -85hp 2/4wd)
5.90 series 800-1004 (from 80hp-100hp 2/4wd)
6.100 series 1104-1304 (from 110hp-130hp 4wd)
Comprehensive product series make your purchasing easily ! ! !
FARM EQUIPMENTS:
EXHIBITION:
CUSTOMER FIRST,
CONTACT UA NOW!!!!!
Cindy Yang
Mob:+86-15515861437
Tel:+86-371-55051327
Fax:+86-371-65316358
E-mail;sales06(at)
Skype;QLN.Cindy.Yang
Website;http://hnqljx.en.china.cn/
http://hnqianli.en.china.cn/
If you are interested in our tractor, we will give you the reasonable price and the best quality guarantees!!
