Specifications
80hp 4wd farm tractor mounted sprayers1.Engine: YTO/YUCHAI
2.Large PTO Dual-stage clutch
3.Hydraulic steering
80hp 4wd farm tractor mounted sprayers
TECHNOLOGY CREATING THE FUTURE
Based on agricultural machinery for the benefit of millions peasants
Henan Qianli Machinery—rise in the modernization of agricultural machinery manufacturing base
80hp 4wd farm tractor mounted sprayers
Specification:
| Basic configuration | |||
| Model | QLN-850B/854B | ||
| Dimensions | Length×Width×Height(mm) | 4010×1915×2750 | |
| Wheel Tread(mm) | Front Wheel(mm) | 1400(2WD)1460(4WD) | |
| Rear Wheel(mm) | 1530—1830(2WD 4WD) | ||
| Min.Ground Clearance(mm) | 430(2WD) 340(4WD) | ||
| Dry Mass | With Cab(kg) | 2800(2WD) 2880(4WD) | |
| Without Cab(kg) | 2585(2WD) 2665(4WD) | ||
| Engine | Trade Mark or Brand | YTO/YUCHAI | |
| Engine Mode | Vertical Water Cooled 4-stroke | ||
| Directly Injection | |||
| Number of Cylinder | 4 | ||
| Cooling System Type | Water Cooled | ||
| Rated Power(kw) | 59 | ||
| Max. Torsion(N.M) | 320 | ||
| Rated Speed(r/min) | 2300(YCD4J11T,LR4B5,YC4A100),2200(YT4B,YC4A90) | ||
| Fuel Tank | Volume(L) | 78 | |
| Transmission System | Clutch | Single,Dry,Dual Stage Type | |
| Gear box | F8+R2 | ||
| Differential | Closed 4-planetary Gears | ||
| Differential Lock | Mechanical Sliding Sleeve | ||
| Braking System | Wet Double Plate Disc Brake | ||
| Running System | Tyre Model | F/R | 6.5-20/14.9-30 |
| F/R(optional) | 8.3-24/14.9-30 | ||
| Steering System | Hydraulic Wheel Steering | ||
| Working Device | Hydraulic System Type | Partial separated Lifter | |
| Linkage Type | II Rear Mount 3-point Linkage | ||
| PTO(Standard) | φ35,6teeth / φ38,8teeth | ||
| PTO Speed(r/min) | 540/760 | ||
| Drawbar Type | Fixed Drawbar | ||
| Optional configuration | |||
| Cab | AC | Heater | Airbrake |
| Adjustable Comfort Seat | Multiple Unit Valve | ROPS | Sunvisor |
| Double Crush Lifter | Radio | CD Player | Trailer |
| Bob-weight | Front BallAst | 11×20=220kg 20kg/pcs | |
| Rear Ballast | 2×80=160kg 80kg/pcs | ||
| Paddy Tyre | F/R | 6.5—20/11—32 | |
| F/R(optional) | 8.3—24/11—32 | ||
80hp 4wd farm tractor mounted sprayers
Details:
1- Famous brand: Qianli Niu brand with long history and good reputation in China
2- Top quality: successfully passed ISO 9001 international quality certification system and China 3C quality system
3- Famous brand engines: strong power, low oil consumption, easy starting, and good economic performance
4- High adaptability: matches all kinds of agricultural implements
5- Diverse gear combinations: creeping shift and shuttle shift
6- Comfortable operation: full hydraulic system
80hp 4wd farm tractor mounted sprayers
