Specifications
agricultural machiner ace tractors:with YTO/YUCHAI engine
Gear type:F8+R2
PTO speed:540/760r/min
Rated power:.59kw
QLN800B 2WD Farm tractor chinese agricultural machinery ace tractors
1. High adaptability to farming for meshing sleeve gear shift(8+4) or crawling gear(16+8) (according to your demands)
2. Operating for long time for an increased oil box
3. Higher reliability while operating in the paddy field for a front transaxle, which is perfectly closed;
4. Higher safety while operating for a National-Type-Approval security framework;
5. Operating as a farming machine in various fields and transporting machine for an air brake
6. Higher reliability for a Power-Take-off equipment which is enhanced;
7. High reliability and strong power for their engines
products pictures
technical parameters
| Model | QLN-800B/804B | ||
| Dimensions | Length×Width×Height(mm) | 4010×1915×2750 | |
| Wheel Tread(mm) | Front Wheel(mm) | 1400(4WD) 1460(2WD) | |
| Rear Wheel(mm) | 1530—1830 | ||
| Min.Ground Clearance(mm) | 430(2WD) 340(4WD) | ||
| Dry Mass | With Cab(kg) | 2800(2WD) 2880(4WD) | |
| Without Cab(kg) | 2585(2WD) 2665(4WD) | ||
| Engine | Trade Mark or Brand | YTO/YUCHAI | |
| Engine Model | Vertical Water Cooled 4-stroke | ||
| Directly Injection | |||
| Number of Cylinder | 4 | ||
| Cooling System Type | Water Cooled | ||
| Rated Power(kw) | 59KW | ||
| Max. Torsion(N.M) | 320 | ||
| Rated Speed(r/min) | 2300(YCD4J11T,LR4B5,YC4A100),2200(YT4B,YC4A90) | ||
| Fuel Tank | Volume(L) | 78 | |
| Transmission System | Clutch | Single,Dry,Dual Stage Type | |
| Gear Box | F8+R2 | ||
| Differential | Closed 4-planetary Gears | ||
| Differential Lock | Mechanical Sliding Sleeve | ||
| Braking System | Wet Double Plate Disc Brake | ||
| Running System | Tyre Model | F/R(2WD) | 6.5—20/14.9—30 |
| F/R(4WD) | 8.3—24/14.9—34 | ||
| Steering System | Hydraulic Wheel Steering | ||
| Working Device | Hydraulic System Type | Positive lifter | |
| Linkage Type | II Rear Mount 3-point Linkage | ||
| PTO(Standard) | φ38,8teeth φ35,6teeth | ||
| PTO Speed(r/min) | 540/760 | ||
| Drawbar Type | Fixed Drawbar | ||
| Optional configuration | |||
| Cab | AC | Heater | Air-brake |
| Adjustable Seat | Multiple Unit Valve | ROPS | Sunvisor |
| Double Crush Lifter | Radio | CD Player | Paddy Tyre |
| Bob-weight | Frontballest | 11×20=220kg 20kg/pcs | |
| Rearballast | 2×80=160kg 80kg/pcs | ||
| Paddy Tyre | F/R | 6.5—20/11—32 | |
| F/R(optional) | 8.3—24/11—32 | ||
| Main devices | Optional devices |
| •4 cylinder diesel engine | Normal fan cab |
| •Gearbox: ; F16+R8 (with creeper) | Luxury cab |
| •2 Wheel-drive | Roll bar |
| •Hydraulic power steering | Sunshade |
| •Hydraulic Output Valve | Air-conditioning |
| •Differential lock | Heater |
| •Dual speed PTO | Lovol engine |
| •Dual clutch, independent operation | Front Counter weight (220kg) |
| •Partial separated hydraulic hitch | Rear Counter weight (160kg/layer, max 4 layer) |
| •Draft positional adjustable | Air-brake |
| •Category Ⅱ Rear-mounted three-point linkage | Hi-pressure devices |
| Paddy tire | |
| Swing drawbar |
QLN tractor have over 70 types tractor mainly in 6 series
1.30 series 250-354 (from 25hp-35hp 2/4wd)
2.40 series 400-554B (from 40hp-55hp 2/4wd)
3.50 series 550-654 (from 55hp-65hp 2/4wd)
4.80 series 700-854B (from 70hp -85hp 2/4wd)
5.90 series 800-1004 (from 80hp-100hp 2/4wd)
6.100 series 1104-1304 (from 110hp-130hp 4wd)
matched implements
our honor
our company
Henan Qianli Machinery Co. Ltd has 25 years professional manufacturer.
Qianli now covers an area of 11 hectare and has 13 modernized process lines.
Our products have been exported to many other countries,
Such as Romania, Russia, Ukraine, Tanzania, Thailand, Australia, etc.
our clients
Please dO not hesitate tO contact us, if you are satisfied with Our products !!!
lOOking forward tO cooperating with yOu !!!
