QLN-604 4WD farm/agricultural good quality tractors; 50-65hp tractor

Specifications

1.Equipped with famous engine
2.12F+12R collor shift
3.Good quality tractor
4.QLN-604 farm/agricultural good quality tractor



Welcome to Qianli Machinery Co., Ltd.

Henan Qianli Machinery Co., Ltd, is a professional manufacturer of agricultural machines. With 25 years development, Qianli now covers an area of 11 hectare and has 13 modernized process lines.  Our products have been exported to many other countries, such as Romania, Russia, Ukraine, Tanzania, Thailand, Australia, etc.





1.PARAMETER





1. QLN600/604 farm tractors are 50hp tractors, specially used in mountain areas and muddy roads.

2. 4in1 combined light is used in the front, and modular lights can provide good lighting at night.

3. Successfully passed ISO9001 International Quality Certification System;

4. It has the characteristics of high transmission efficiency, low tremble, high traction, high adaptability and easy start.

5. Hydraulic output interface can make direct connection with the dump trailer, mower, backhoe, plough, etc.

6. This series tractor can have many different configurations according to customer’s demands: F12+R12 where the creeping shift can be selected, fixed or adjusted tread, back catalogue suspensions, mechanical steering or hydraulic steering and so on.



Model	QLN 604
Drive type	4×4
Technical parameter
Dimension(L×W×H)(mm)	3980×1635×2150
Wheel base (mm)	2150
Wheel tread F/R (mm)	1400/1300~1600
Adjust method of wheel tread	Level adjustment
Min. ground clearance (mm)	325
Ballast F/R (KG)	144/360
Engine
Engine type	Vertical ;water cooled ;             4-stroke ;direct injection
Brand	Quanchai ;YTO ; Yuchai
Volume of fuel tank (L)	43
Rated power (kW)	44
Rate oil consumption rate	≤2.04
Transmission
Clutch	Single,dry,dual-stage
Gear box	12F+12R
Speed of PTO (r/min)	540/760
Steering system
Steering system type	Hydraulic steering
Working device
Model of suspension mechanism	Rear mounted, 3-point linkage, categoryⅠ or Ⅱ
Tilling depth control type	Floating control (separated)
Max. lifting force at suspension point 610 mm (kN)	≥10.0
Hydraulic output valve	A pair (multi-way valve)
PTO specification	Φ38×8 or Φ35×6 or Φ34.67×21





(1) Equipped with famous engine
(2) 12F+12R collor shift
(3) QLN-604 4WD farm/agricultural good quality tractors

2.QLN604 4WD  60HP  Tractor with cabin











2.Tractor in the exhibition/

      QLN-604 4WD farm/agricultural good quality tractors







3.Famous engine featuring strong power, high reliability, and large torque reserve factor.









QLN tractor have over 70 types tractor main in 6 series.Let me show you below:

1.35 series 250-354 (from 25hp-35hp 2/4wd)

2.40 series 400-554B (from 40hp-55hp 2/4wd)

3.55 series 550-654 (from 55hp-65hp 2/4wd)

4.80 series 700-854B (from 70hp -85hp 2/4wd)

5.90 series 800-1004 (from 80hp-100hp 2/4wd)

6.100 series 1104-1304 (from 110hp-130hp 4wd)



Comprehensive product series make your purchasing easily ! ! !





4.More details

Comfortable seat









Steering wheel













Work device











5. QLN’ Production line



















6. Visitors from the world



                       Welcome to visit our factory



















7.Kinds of farm equipment

















8.Quality guarantee







 9.Sales network









 With good quality and competitive price, our products have beenexported to Romania,Russia, Ukraine,Tanzania, Congo, Iraq,Thailand, Malaysia,Australia, Venezuela,Chile, etc.
