Home > Products > 40 series (40-55HP) wheel tractor > QLN404 cheap wheel mini tractor truck
QLN404 cheap wheel mini tractor truck
- 6000 Set / Sets per Month
- Qingdao/Tianjin/Shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Wheel Tractor | By wheel: | 4WD |
Usage: | Farm Tractor | Drive Type: | Gear Drive | Power(W): | 29.4 |
Certificate: | Other, ISO9001:2008 | Brand Name: | Qianli Niu | Model Number: | QLN |
Place of Origin: | Henan, China | After-sales Service Provided: | Overseas service center available |
Product Description
Specifications
cheap wheel mini tractor truckDouble-cylinder hydraulic steering
Gear box withF8+R4
Dual plates oil-bath disc bra
QLN cheap wheel mini tractor truck
Detailed description
- F8+R4 gear change, all gears are arranged in order, good adaptability in all agriculture conditions.
- 540/1000rpm, 760/1000rpm double speed PTO systems, high operation efficiency.
- Closed paddy rice front drive axle, high operation efficiency and suitable for paddy operation.
- Optional air brake can complete more farm work and transport operation.
- Reinforced PTO shaft, hi-reliability.
- Can install famous domestic engines like Guangxi Yuchai, YTO Brands, powerful and reliable.
garden tractor Pictures
Technical parameters
Basic configuration | |||
Model | QLN-550B/554B | ||
Dimensions | Length×Width×Height(mm) | 3615×1750×2150 | |
Wheel Tread(mm) | Front Wheel(mm) | 1300 | |
Rear Wheel(mm) | 1300—1500 1300 nomally | ||
Min.Ground Clearance(mm) | 325 | ||
Dry Mass | Complete tractor weight(KG) | 2280 | |
Engine | Trade Mark or Brand | JIANGDONG/XINCAI | |
Engine Model | Vertical Water Cooled 4-stroke | ||
Directly Injection | |||
Number of Cylinder | 4 | ||
Cooling System Type | Water Cooled | ||
Rated Power(kw) | 29.4KW | ||
Rated Speed(r/min) | 2200(YCD4J11T-65),2300(YT4A2-23) | ||
Fuel Tank | Volume(L) | 43 | |
Transmission System | Clutch | Single,Dry,Dual Stage Type | |
Gear Box | F8+R4 | ||
Differential | Closed 4-planetary Gears | ||
Differential Lock | Mechanical Sliding Sleeve | ||
Braking System | Mechanical,dry type | ||
Running System | Tyre Model | F/R(2WD) | 6.0—16/12.4—28 |
F/R(4WD) | 8.3—20/12.4—28 | ||
Steering System | Mechanical for 2wd tractor and Hydraulic steering for 4wd tractor | ||
Working Device | Hydraulic System Type | Partial seperated lifter | |
Linkage Type | I Rear Mount 3-point Linkage | ||
PTO(Standard) | Φ38×8 or Φ35×6 or Φ34.67×21 | ||
PTO Speed(r/min) | 540/760 | ||
Drawbar Type | Fixed Drawbar | ||
Optional configuration | |||
Cab with Heater | Multiple Unit Valve | ROPS | Sunvisor |
Adjustable Comfort Seat | Paddy Tyre | Heater | Swing Drawbar |
PTO Speed(r/min):540/1000 760/1000 | |||
Bob-weight | Frontballest | 8×10=80kg 10kg/pcs | |
Rearballast | 2×30=60kg 30kg/pcs |
Main types
QLN has over 70 types tractors mainly in 6 series.
1. 35 series 250-354 (from 25hp-35hp 2/4wd)
2. 40 series 400-554B (from 40hp-55hp 2/4wd)
3. 50 series 550-654 (from 55hp-65hp 2/4wd)
4. 80B series 700-854B (from 70hp -85hp 2/4wd)
5. 80A series 800-1004 (from 80hp-100hp 2/4wd)
6. 100 series 1104-1304 (from 110hp-130hp 4wd)
