Help CenterQLN404 Mini Wheel Farm Tractor Cabin
US$ 4,960 - 8,560
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Tianjin/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
QLN404 Mini Farm Equipment and Tractores+chinos for SaleUS$ 4,960 - 8,560MOQ: 1 Set -
QLN404 Mini Farm Equipment and Tractors for SaleUS$ 4,960 - 8,560MOQ: 1 Set
-
QLN 304 Farm Wheel Mini Farmtrac TractorsUS$ 3,306 - 6,860MOQ: 1 Set
-
QLN 304 Farm Wheel Tractor Mini Farm TractoresUS$ 3,306 - 6,860MOQ: 1 Set
-
QLN 304 Farm Wheel Tractor and Farm Poultry Equipment for SaleUS$ 3,306 - 6,860MOQ: 1 Set
Condition
New
Type
Wheel Tractor
By wheel
4WD
Usage
Farm Tractor
Drive Type
Gear Drive
Power(W)
29.4
Certificate
Other, ISO9001:2008
Brand Name
Qianli Niu
Model Number
QLN
Place of Origin
Henan, China
After-sales Service Provided
Overseas service center available
Specifications
mini wheel farm tractor cabinDouble-cylinder hydraulic steering
Gear box withF8+R4
Dual plates oil-bath discbrake
QLN mini wheel farm tractor cabin
Detailed description
- F8+R4 gear change, all gears are arranged in order, good adaptability in all agriculture conditions.
- 540/1000rpm, 760/1000rpm double speed PTO systems, high operation efficiency.
- Closed paddy rice front drive axle, high operation efficiency and suitable for paddy operation.
- Optional air brake can complete more farm work and transport operation.
- Reinforced PTO shaft, hi-reliability.
- Can install famous domestic engines like Guangxi Yuchai, YTO Brands, powerful and reliable.
Pictures
Technical parameters
| Basic configuration | |||
| Model | QLN-550B/554B | ||
| Dimensions | Length×Width×Height(mm) | 3615×1750×2150 | |
| Wheel Tread(mm) | Front Wheel(mm) | 1300 | |
| Rear Wheel(mm) | 1300—1500 1300 nomally | ||
| Min.Ground Clearance(mm) | 325 | ||
| Dry Mass | Complete tractor weight(KG) | 2280 | |
| Engine | Trade Mark or Brand | JIANGDONG/XINCAI | |
| Engine Model | Vertical Water Cooled 4-stroke | ||
| Directly Injection | |||
| Number of Cylinder | 4 | ||
| Cooling System Type | Water Cooled | ||
| Rated Power(kw) | 29.4KW | ||
| Rated Speed(r/min) | 2200(YCD4J11T-65),2300(YT4A2-23) | ||
| Fuel Tank | Volume(L) | 43 | |
| Transmission System | Clutch | Single,Dry,Dual Stage Type | |
| Gear Box | F8+R4 | ||
| Differential | Closed 4-planetary Gears | ||
| Differential Lock | Mechanical Sliding Sleeve | ||
| Braking System | Mechanical,dry type | ||
| Running System | Tyre Model | F/R(2WD) | 6.0—16/12.4—28 |
| F/R(4WD) | 8.3—20/12.4—28 | ||
| Steering System | Mechanical for 2wd tractor and Hydraulic steering for 4wd tractor | ||
| Working Device | Hydraulic System Type | Partial seperated lifter | |
| Linkage Type | I Rear Mount 3-point Linkage | ||
| PTO(Standard) | Φ38×8 or Φ35×6 or Φ34.67×21 | ||
| PTO Speed(r/min) | 540/760 | ||
| Drawbar Type | Fixed Drawbar | ||
| Optional configuration | |||
| Cab with Heater | Multiple Unit Valve | ROPS | Sunvisor |
| Adjustable Comfort Seat | Paddy Tyre | Heater | Swing Drawbar |
| PTO Speed(r/min):540/1000 760/1000 | |||
| Bob-weight | Frontballest | 8×10=80kg 10kg/pcs | |
| Rearballast | 2×30=60kg 30kg/pcs | ||
Main types
QLN has over 70 types tractors mainly in 6 series.
1. 35 series 250-354 (from 25hp-35hp 2/4wd)
2. 40 series 400-554B (from 40hp-55hp 2/4wd)
3. 50 series 550-654 (from 55hp-65hp 2/4wd)
4. 80B series 700-854B (from 70hp -85hp 2/4wd)
5. 80A series 800-1004 (from 80hp-100hp 2/4wd)
6. 100 series 1104-1304 (from 110hp-130hp 4wd)
