Compact and Utility 2.5 Tons YZC2.5 Double Drums Vibratory Rollers for Road Construction
The machine is a small-size Tandem Vibratory Roller, it is applied to mending and maintaining various roads, expressway shoulder, side walk, parking area, sports ground and garden lawn. It is especially suited for compaction of pipeline channel and drainage trench etc. narrow areas.
Main Features:
- Mechanical travel drive, hydraulic vibration and steering, with reliable performance and function/worth ratio and actively in operation.
- Reliable engine of ChangChai with large power storage, reliable performance, stable quality, low oil consumed, easy to convenient operation and maintenance.
- Compact design and small size and beautiful appearance, it is suited for compaction of narrow areas.
- Scrapers and sprinkling devices on all drums, to develop the quality of construction.
- Covering pergola adopt umbrella pergola or glass-steel pergola.
Technical Specifications:
MDOEL |
|
YZC2.5 |
Operating mass |
Kg |
2500 |
Front static linear load |
N/cm |
117 |
Rear static linear load |
N/cm |
154 |
Inspire force |
kN |
25 |
Vibration frequency |
HZ |
50 |
Drum width |
mm |
900 |
Drum diameter |
mm |
750 |
Max steering radius |
mm |
4300 |
Grade ability |
% |
20 |
Tread width |
mm |
1980 |
Max.travel speed |
Km/h |
5.6 |
Engine model |
|
CZ380Q |
Normal rated power |
kW |
14.7 |
Sprinkler tank capacity |
L |
80 |
Oil tank capacity |
L |
60 |
Total length |
mm |
2765 |
Total width |
mm |
1200 |
Total height |
mm |
2580 |
