Characteristics:
(1) The mixer is Twin Shafts Horizontal Compulsion mixing type. The machine is designed at modules which each one is a independent function unit. It is easy to transmit and install with well adaptability.
(2) This kind of equipment is suit to fabricate the cement concretes with various characters. It is widely used in construction projects of highway, hydro-station, bridge, port, airport, as well as civicism.
(3) The machine adopts “industrial computer + PLC + specialize counting meters” control form instead of traditional “VB language program” control, which greatly increases reliability and stability of the system.
Technical data:
Model |
HZSS90 |
|
Productivity (m3/h) |
90 |
|
Structure type |
Module and Moveable |
|
Full power (kW) |
235 |
|
mixer |
Type |
Cycle Twin Shafts Horizontal Compulsion Mixing |
Model |
BS4000 |
|
Max. aggregate (mm) |
150 |
|
Motor power (kW) |
2×75 |
|
Hopper cubage × Num. |
4×20 m3 |
|
Count type |
Accumulative or Separate Count |
|
Control type |
“Computer + PLC + Count Meter” Control, Batch Weigh and Cycle Operation |
|
Proportion error |
Aggregate ≤2% Powder≤1% water≤1% additive≤1% |
|
Discharge height |
3.8m (Consumer Optional ) |
|
Note:
1. Full power does not include helix feed part.
2. Number and cubage of the aggregate storage, powder storage, and machine lay is optional.
3. The parameters above may be amended and actual data will be according to the product.
