Help CenterChinese Farm Tractor Price With Excellent Quailty GN304, 30HP
Related Products
-
25hp Tractor With `Mechanical Steering for 2WDUS$ 4,000 - 6,000MOQ: 2 Sets -
25 hp Engine Power Farm Tractor With Gear Box for SaleUS$ 4,000 - 6,000MOQ: 2 Sets
-
36 hp Power Engine Tractor With High Quality for SaleUS$ 4,000 - 6,000MOQ: 2 Sets
-
38hp Power 2wd Drive TractorUS$ 4,000 - 6,000MOQ: 2 Sets
-
4 Wheel Small Tractor for SaleUS$ 4,000 - 6,000MOQ: 2 Sets
Product Introduction
GN304 30hp tractor Specifications
1)Type:4*4
2)Tractor Model:GN304
3)Wheel base(mm):1755
Specification
Model |
GN304 |
|
Drive Type |
4×4 |
|
Engine |
|
|
Engine Model |
SD2100TA |
|
Engine Type |
inline,vertical,water-cooled,four-stroke |
|
Cylinder diameter(mm) |
100 |
|
Stroke(mm) |
115 |
|
Max Torque(N·m)/Revolving Speed(rpm) |
≥109.8/≤1650 |
|
Displacement(L) |
1.81 |
|
Fuel Tank Capacity(L) |
51 |
|
Engine Rated Power (kW/rpm) |
22 |
|
Rated Operating Conditions Fuel Consumption Rate(g/kW·h) |
≤250 |
|
Drive Train |
|
|
Clutch |
Dry,single-stage |
|
Standard PTO speed(rpm) |
(540,1000)/(750,1000)/(540,750) |
|
Gears |
8F+2R/10F+2R |
|
Speed range(Km) |
1.9~24.23 |
|
Steering type |
hydraulic steering |
|
Gear Shift Mode |
sliding gear shift |
|
Break System |
|
|
Service Brake |
pedal,mechanical drive,closed shoe type |
|
Parking Brake |
locked pedal |
|
Hydraulic System |
|
|
Hydraulic Output Flow(L/min) |
30 |
|
Hydraulic Output Valve |
1 way(optional) |
|
Working Device |
|
|
Three-Point Suspension |
postposition,Category I |
|
Max.Lifting Capacity(kN) |
≥4.95 |
|
Tillage Depth Adjustment |
draft and position adjustable |
|
General Parameter |
|
|
Overall Dimension(L×W×H)mm |
With cab |
/ |
Without cab |
3125×1455×2115 |
|
Wheelbase(mm) |
1755 |
|
Min. operating weight(kg) |
With cab |
/ |
Without cab |
1580 |
|
Min. Ground Clearance(mm) |
345 |
|
Min.turning radius(mm) |
3000 |
|
Maximum Pull(KN) |
7.84 |
|
Front Tire |
6.5-16 |
|
Rear Tire |
11.2-24 |
|
Optional Disposition |
|
|
|
|
dual-stage clutch, |
|
