Home > Transportation > Tractor & Parts > Tractor > Chinese Factory Direct Supply 4*4 40hp Wheel Mini Farm Tractor With Low Price

Chinese Factory Direct Supply 4*4 40hp Wheel Mini Farm Tractor With Low Price

Chinese Factory Direct Supply 4*4 40hp Wheel Mini Farm Tractor With Low Price thumbnail-1
Chinese Factory Direct Supply 4*4 40hp Wheel Mini Farm Tractor With Low Price thumbnail-2
Chinese Factory Direct Supply 4*4 40hp Wheel Mini Farm Tractor With Low Price thumbnail-3
Chinese Factory Direct Supply 4*4 40hp Wheel Mini Farm Tractor With Low Price photo-1
Chinese Factory Direct Supply 4*4 40hp Wheel Mini Farm Tractor With Low Price photo-2
Chinese Factory Direct Supply 4*4 40hp Wheel Mini Farm Tractor With Low Price photo-3
US$ 5,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Shandong Wolwa Construction Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qindao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 29.4KW
Certificate Other, ISO,CE
Brand Name WOLWA
Model Number GN404
Place of Origin Shandong, China
After-sales Service Provided Overseas service center available

     chinese factory direct supply 4*4 40hp wheel mini farm                                           tractor with low price



Product Description

 specifications:

1.40HP
2.Drive type:4WD
3.Single stage cluth
4.Power steering
5.(8F+2R)gear box
6.Position adjustable lifter
7.Differential lock
8.Dual speed PTO
9.Three-point suspension
10.Front bumper
11.Rear-view mirror

chinese factory direct supply 4*4 40hp wheel mini farm tractor with low pricechinese factory direct supply 4*4 40hp wheel mini farm tractor with low pricechinese factory direct supply 4*4 40hp wheel mini farm tractor with low price

Model GN400 GN404
Drive Type 4×2 4×4
Engine
Engine Model JD490T
Engine Type inline,vertical,water-cooled,four-stroke
Cylinder diameter(mm) 90
Stroke(mm) 105
Max Torque(N·m)/Revolving Speed(rpm) ≥165/≤1725
Displacement(L) 2.67
Fuel Tank Capacity(L) 51
Engine Rated Power (kW/rpm) 29.4
Rated Operating Conditions Fuel Consumption Rate(g/kW·h) ≤245
Drive Train
Clutch Dry,single-stage
Standard PTO speed(rpm) (540,1000)/(750,1000)/(540,750)
Gears 8F+2R/10F+2R
Speed range(Km) 2.17~27.7
Steering type mechanical steering hydraulic steering
Gear Shift Mode sliding gear shift
Break System
Service Brake pedal,mechanical drive,closed shoe type
Parking Brake locked pedal
Hydraulic System
Hydraulic Output Flow(L/min) 30
Hydraulic Output Valve 1 way(optional)
Working Device
Three-Point Suspension postposition,Category I
Max.Lifting Capacity(kN) ≥6.62
Tillage Depth Adjustment draft and position adjustable
General Parameter
Overall Dimension(L×W×H)mm With cab /
Without cab 3315×1490×2105 3360×1490×2100
Wheelbase(mm) 1960 1950
Min. operating weight(kg) With cab /
Without cab 1630 1890
Min. Ground Clearance(mm) 485 365
Min.turning radius(mm) 3200 3300
Maximum Pull(KN) 7.8 12
Front Tire 6.0-16 7.5-16
Rear Tire 11.2-28
Optional Disposition
hydraulic steering dual-stage clutch
dual-stage clutch shuttle gear(creeper gear)
shuttle gear(creeper gear) paddy tire
paddy tire swing draw bar
swing draw bar rear counter weight
ROPS with canopy ROPS with canopy
1 group hydraulic output 1 group hydraulic output
Our Services



Our Guarantee:
Service:
1.Excellent after-sale service teams
2.One year guarantee for the whole machine
3.General inspection on fixing before packing
4.Oversea service center acceptable
Quality control:
1.All products must go through checks before manufacturing process.
2.Every production line is equipped in an individual QC to ensure well-done production.

contact information:

skype:wolwahannah
QQ:2745940132

chinese factory direct supply 4*4 40hp wheel mini farm tractor with low price
