3 Ton Drive on Hydraulic Road Roller Compactor

Name: 3 Ton Drive on Hydraulic Road Roller Compactor
Brand: WOLWA
SKU: 140740798
Availability: InStock

Shandong Wolwa Construction Machinery Co., Ltd.

US$ 10,000 - 15,000 MOQ: 2 Sets

Key Specifications

Condition:

New

Type:

Double Drum Roller

Travel Speed:

0-12km/h

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Double Drum Roller

Travel Speed 0-12km/h

Grade Ability 25%

Place of Origin Shandong, China

Brand Name WOLWA

Model Number GNYL61

Power(W) 24.4kw/2800rpm

Dimension(L*W*H) 2750mm*1410mm*1900mm

Weight 2900kg

Certification iso and ce

After-sales Service Provided Engineers available to service machinery overseas

Product Description

1. Imported Sauer hydraulic variable plunger pump, drives the machine stepless speed walking.

2. Double Poclain plunger motors drive the machine walking.

3. Italian brand motor drives the steel drum vibrating.

4. Extra-large plastic water tank, free from corrosion and convenient for the water-spraying.

5. Double control levers with vibration button, makes the compaction of edge easy.

6. Electrically controlled water-spray, high efficient and water-saving.

7. Wear-resistant scraper can be lift and fixed during transportation.

8. LED lamp at front and rear for the convenience of night construction.

Type	GNYL61	GNYL61B				GNYL61N
Run
Speed	0-12km/h
Turning radius	2600mm
Climbing capacity in theory	40%
Compaction
Static load forward/back	118/110N/cm
Nominal amplitude	0.5mm
Vibration frequency	60Hz
Exciting force	30kN		2 x 30kN			30kN
Water tank volume	200L
Working
Drive	Variable plunger pump, radial plunger hydraulic motor
Vibration	Gear pump, Gear motor
Turning	Hydraulic steering
Engine
Model	Perkins 403D-15				CHANGCHAI N385
Type	Diesel engine, water-cooled, 4stroke, three cylinder
Power	24.4kW/2800rpm				24kW/2800rpm
Fuel tank volume	40L
Lubricant L	6L
Fuel consumption	276g/kWh			260g/kWh
Dimension
Width of steel wheel	1200mm
Diameter of steel wheel	700mm
Total length	2495mm
Total width	1310mm
Total height	2440mm
Tread	1760mm
Packing size	2810×1460×2100mm
Weight
Working weight	2900kg
