DLS958 5ton coal bucket wheel loader
- 50 Set / Sets per Month
- Qingdao Tianjin Shanghai
- T/T
Product Details
Condition: | New | Brand Name: | Wolwa | Model Number: | DLZ958 |
Place of Origin: | Shandong, China | Type: | Front Loader | Moving Type: | Wheel Loader |
Dimension(Long * Breadth * High): | 8110*3070*3490mm | Rated Load: | 5000kg | Certification: | CE & ISO9001:2008 |
Warranty: | 1 year | After-sales Service Provided: | Overseas third-party support available |
Product Description
DLS958 5ton coal bucket wheel loader
1. Adopt Weichai Steyr diesel engine is adopted, with large torque backup and strong power.
2. Single stage, 4 elements, twin turbo ZL50 torque converter and planetary gearbox from Hangzhou Advance Gearbox Group, compact structure and high reliability.
3. Gear-shift with 2 forward and 1 reverse controlled by flexible shaft eases much labor.
4. Strengthened axles own large bearing capacities and high reliability.
5. Twin pump merging hydraulic system makes lower consumption and excellent performance.
6. The coaxes flow-amplified, hydraulic compensated steering makes operation easy and performance reliable.
7. Both travel system and working hydraulic system are forced-cooled, improving the efficiency obviously.
8. Air over hydraulic brake system; eight caliper disc brakes.
9. Air break control, expand hoof type parking brake and emergency brake.
10. Working device with automatically leveling ability at high position.
11. Main articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
12. Integral, luxury instrument board.
13. New, luxury cabin.
DLS958 5ton coal bucket wheel loader
Item | Specifications | Item | Specifications |
Bucket Capacity | 3m3 | Min. Turning Radius (outside of rear wheels) | 6288mm |
Rated Load | 5000 kg | Steering Angle | 35º |
Dumping Height | 3100 mm | Min. Ground Clearance | 500mm |
Dumping Reach | 1280mm | Wheel Base | 3200mm |
Boom Lifting Time | 6s | Tread | 2250mm |
Total Cycling Time | 12s | Engine Model | WD615G220 |
Max. Speed | 38km/h | Rated Power | 162kw/2200rpm |
Max. Breakout Force | 170kn | Tire Type | 23.5-25 |
Max. Drawing Force | 150kn | Overall Dimensions | 8110*3070*3570mm |
Max. Gradeability | 30° | Operating Weight | 17000kg |
Optional: Cummins engine 6CTA8.3-C215
DLS958 5ton coal bucket wheel loader
•Direct factory supplier ,Well and High Quality Control
Shandong Wolwa Construction Machinery Co., Ltd, a corporate enterprise of Wolwa Group, is a professional hydraulic excavator manufacturer integrating scientific research, production and sales. Wolwa Group Co., Ltd has the total assets of 2.5 billion RMB. It has over 80,000 square meters of production workshop with international advanced level and 8,000 square meters of R & D center. It has the production capacity with an annual output of 10,000 sets of construction machinery and 20,000 sets of hydraulic parts. The company has the honors of National High-tech Enterprise, he Leader of Local SMES and Shandong Top 100 Enterprise.
Our main leading products are DLS865-9A DLS880-9A DLS890-9A DLS100-9A Wheeled Hydraulic Excavator, DLS880-9A DLS890-9A Wheeled Sugarcane Wood Loader, DLS118-9A Wheeled Hydraulic Stacker, DLS865-9B DLS865-10B DLS880-9B DLS100-9B DLS130-9 DLS160-9 Crawler Hydraulic Excavator etc.
We also specializes in the sales of other construction machinery and agricultural equipment such as desiccated underground crusher, welding workstation, truck cranes, wheel loaders, skid steer loaders, concrete mixer trucks, forklifts, road rollers, harvesters, tractors, steel bar processing machinery and so on.
Our company has passed the ISO9001:2008 authentication, and got European Union CE certificate. Our products are exported to many countries such as Russia, Belarus, Iran, Vietnam, Five Central Asian Countries, Africa and other countries all over the world.
