Weichai Steyr diesel engine is adopted, with large torque backup and strong power.
Single stage, 4 elements, twin turbo ZL50 torque converter and planetary gearbox from Hangzhou Advance Gearbox Group, compact structure and high reliability.
Strengthened axles owns large bearing capacities and high reliability.
Twin pump merging hydraulic system makes lower consumption and excellent performance.
The coaxes flow-amplified, hydraulic compensated steering makes operation easy and performance reliable.
Double seal cutting sleeve type hydraulic hose connector has solved the leakage problem
Both travel system and working hydraulic system are forced-cooled, improving the efficiency obviously.
Air over hydraulic brake system; Eight caliper disc brakes.
Air break control, expand hoof type parking brake and emergency brake.
Working device with automatically levelling ability at high position
Integral, luxury instrument board.New, luxury cabin.
Optional:shangci engine,the boom lifting limit device.
Item |
Specification |
Item |
Specifications |
Bucket capacity | 3 m3 |
Min. turning radius (outside of rear wheels) | 6288mm |
Rated load | 5000 kg |
steering angle | 35º |
Dumping height | 3410mm |
Min. ground clearance | 500mm |
Dumping reach | 1230mm |
Wheel base | 3200mm |
Boom lifting time | 6 S |
Tread | 2250mm |
Total cycling time | 12 S |
Engine model | Weichai steyr |
Max. speed | 37km/h |
Rated power | 162kW/2200rpm |
Max. breakout force | 170 kN |
Tyre | 23.5-25 |
Max.drawing force | 150 kN |
Overall dimensions | 8190*3070*3570mm |
Max. Gradeability | 30° | Operating weight | 16500kg |
|
|
