Engine type: Made by SINOTRUK, six cylinders inline, two valve, supercharge postposition, superchage intercooler.
Clutch: D430 diaphragm spring clutch, hydraulic control air assisted.
Transmission: SINOTRU HW series 10 gerars transmission, transmission with main and auxiliary transmission structrue,
main transmission with doulbe counter shaft, auxiliary transmission with planetary reduction. With WD615.69,WD615.47 standard HW19710
Front axle: HF9,drum-type, rated load of 9 ton.
Driving Axle: HC16 double reduction(central reduction + wheel reduction), speed ration:5.73,4.8
Option:AC16 axle
Pattern: Central reduction + hub reduction, cast axle housing
Rated axle loading: 16000kg/2*16000kg, speed ratio: 4.77/5.45/6.5, suit for severe road conditions and high road operating environment, optimal for heavy engineering trucks
Suspension: front and rear leaf spring suspension, front suspension with shock absorber, transverse stabilizer, rear suspension is disconnected type with transverse stabilizer.
Steering system: ZF8098 Steering gear, ZF steering oil pump, system pressure 18MPa
Brake system:
sevice brake: dual-circuit air pressure brake; paking brake: spring storage energy without air;auxilliary brake:
Engine exhaust braking; Engine EVB is optional and With ABS and optional auto clearance adjusting arm.
Tyre: 315/80r22.5
Cabin: HW76, one sleeper with air conditioner.Option: HW70, no sleeper with air conditioner
Truck Model |
ZZ3257N3647B |
||||
Driving Type |
6X4 |
||||
Truck Brand |
hot sale dump truck howo dump truck heavy duty dumper truck fuel diesel truck tipper 30t 40t 50t howo dumper trucks |
||||
Dimension(Lx W xH)(unloaded)(mm) |
8214*2496*3170 |
||||
Cargo body size (L*W*H, mm) (mm) |
5400x2300x1400, bottom:8mm, side:6mm 18.63m3 |
||||
Lift type of Carriage |
Front lifting |
||||
|
Approaching angle/Departure angle(°)
|
19/30 |
||||
Overhang(front/rear) (mm) |
1500/1560 |
||||
Wheel base (mm) |
3625+1350 |
||||
Max speed(km/h) |
75 |
||||
Curb weight(kg) |
12220 |
||||
Fuel tanker capacity(L) |
300 |
||||
Fuel consumption(L/km) |
20-40 L/100 km |
||||
Clutch |
Single-plate dry clutch Φ430mm |
||||
|
Engine Model (Steyr technology, made in China) |
Fuel type |
Diesel |
|||
Horse Power, max(kw/rpm) |
336HP,247/2200 |
||||
Emission |
EURO II |
||||
Model |
WD615.69, water-cooled,four strokes 6 cylinders in line with water cooling, turbocharged and intercooling, directly injection |
||||
Transmission |
Model |
HW15710,10 forwards and 2 reverse |
|||
|
Brake system
|
Service brake |
Dual circuit compressed air brake |
|||
Parking brake |
spring energy, compressed air operating on rear wheels
|
||||
Auxiliary brake |
Engine exhaust brake |
||||
|
Steering system
|
Model |
ZF8098 hydraulic steering with power assistance |
|||
Front axle |
HF9 , Steering with double T-cross section beam |
||||
Rear axle |
HC16, casting axle housing, central double reduction with differential locks between axles and wheels |
||||
Color |
Red,White,etc |
||||
Tyre |
315/80r22.5 |
||||
|
Electrical system
|
Battery |
2X12V/165Ah |
|||
Alternator |
28V-1500kw |
||||
Starter |
7.5Kw/24V |
||||
Cab |
HW70 cab, (one sleeper, with air-condition), all-steel forward control, 55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers |
||||
