China Manufacture 4m3 Concrete Mixer Truck From Wolwa

China Manufacture 4m3 Concrete Mixer Truck From Wolwa thumbnail-1
China Manufacture 4m3 Concrete Mixer Truck From Wolwa thumbnail-2
China Manufacture 4m3 Concrete Mixer Truck From Wolwa thumbnail-3
China Manufacture 4m3 Concrete Mixer Truck From Wolwa photo-1
China Manufacture 4m3 Concrete Mixer Truck From Wolwa photo-2
China Manufacture 4m3 Concrete Mixer Truck From Wolwa photo-3
US$ 20,000 - 25,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
wolwa
Contact Supplier Request Quote Chat Now
Shandong Wolwa Construction Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name wolwa
Model Number GN4CBM
Weight 13570
Dimension(L*W*H) 6460*2250*3300
Power(W) 96kw
Certification CE,ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

wolwa 4m3 concrete mixer truck made in china



 china manufacture 4m3 concrete mixer truck from wolwa



china manufacture 4m3 concrete mixer truck from wolwa



china manufacture 4m3 concrete mixer truck from wolwachina manufacture 4m3 concrete mixer truck from wolwa



Product Name: 4 CBM of concrete mixer truck

Engine Model: YC4D130-41

Chassis Type: Fukuda BJ1143VJPFA-1

Engine type: forced circulation cooling

The total mass: (kg) 13570 Engine

Displacement: 4200

Vehicle size: 6460 * 2250 * 3300

Engine power: (kw) 96

Max.  Standard transfer rate: (r / min) 3200

Wheelbase: (mm) 3400

Drum geometric volume: (m³) 6.3

Front axle: (mm) 1230

Max. mixing volume: (m³) 4

Rear overhang: (mm) 1830

Feed rate: (m³) ≥ 0.5

Maximum grade: 25

Feeding speed: (m³) ≥ 0.8

Maximum speed: (km / h) ≤ 83

Maximum speed: (r / min) 6-15

Minimum turning diameter: (m) ≤ 15

Drum inclination: (°) 16

Clutch: Twin-plate dry mix bucket often engages

Max. diameter: (mm) 1900

Transmission Type: shaft

Drive gear: HJ200.43

Drive mode: rear-wheel drive

Hydraulic pumps: the right to spend 40 gear pump

Steering Type: hydraulic power

Hydraulic motors: Orbit Motors

Brake: breathe brake

Tank capacity: (L) 180

Parking brake: air brake Brake

Water supply: water supply pressure

Tire :825-20

china manufacture 4m3 concrete mixer truck from wolwa
