SINOTRUK HOWO ZZ3317N3867W 8X4 Dump Truck For Sale
Model |
ZZ3317N3867W |
|
Cabin |
HW76 cab. Original luxury Volvo cab with sleeper. |
|
Vehicle Main Dimensions |
L×W×H(mm) |
10745×2496×3190,3406 |
Wheel base(mm) |
1800+3600+1350 |
|
Wheel track (mm) |
1840 |
|
Approach/Departure angle(°) |
28/17 |
|
Weight in KGS |
Tare Weight |
15120 |
Loading Capacity |
15750 |
|
Front axles loading capacity |
1×8000 |
|
Rear axles loading capacity |
2×8500 |
|
Max.Drinving Speed (km/h) |
90,102 |
|
Engine |
Brand |
HOWO |
Model |
WD615.69 |
|
Type |
6-cylinder in-line with water cooling; 4-stroke direct injection; turbo-charging and inter-cooling |
|
Horse Power(HP) |
266hp/290hp/300hp/336hp/375hp |
|
Emission Standard |
Euro II |
|
Axle |
HC16, overall cast steel axle and Han Ruisen disconnect suspension |
|
Gearbox |
HW19710.10 block transmission |
|
Clutch |
Reinforced diaphgragm clutch, diameter 430mm |
|
Steering Gear |
ZF8098, original made in German. Power steering, hydraulic steering with power assistance. |
|
Fuel Tank(L) |
300L |
|
Tire |
12.00R20 |
|
Brakes |
Service brake: dual circuit compressed air brake Parking brake: spring enengy, compressed air operating on rear wheels Auxillary brake: engine exhaust valve brake |
|
Dump Body | ||
Thickness |
Side |
6mm in high tensile strength steel Q345B |
Front |
6mm in high tensile strength steel Q345B |
|
Bottom |
8mm in high tensile strength steel Q345B |
|
Dump Body Size |
L×W×H |
7800 x 2300 x 1200(1500) |
Tipping Hydraulics |
Tipping Type |
Front tipping type |
Tipping System |
Complete set of HYVA brand hydraulics system |
|
The warranty covers the Product, for one (1) year from the documented date of purchase.
We promise excellent service under the warranty:
1. We will send the new spare parts by air express, such as DHL or TNT once our customers request an urgent replace of broken parts under warranty
2. We will arrange engineers to service machinery overseas in case our customers are in need help for installation and training, such as tower cranes, concrete batching plant, asphalt mixing plant, stone crushing plant, etc.
3. We will send original spare parts by shipment or air express for option in case our clients want to purchase some other spare parts for repair and regular maintenance of their machines.
As a leading exporter specially for a big variety of construction equipment, Shanghai Dobest Construction Machinery Co., Ltd. is located in China's biggest port city Shanghai, which is also the financial center and business center.
Our mission is to provide a 'one-stop' service to fulfill our customers’ needs and expectations with the high quality product, prompt delivery and perfect service after sales. We promise to do our best to make our customers satisfied as we offer professional construction solutions for their kinds of projects.
By keeping the principle of good quality, competitive price, superior service, now we have won a very good reputation from all of our customers all over the world. Thus, our business expanded rapidly and so far we have exported our products to more than 20 countries and regions, including Australia, New Zealand, Brazil, Argentina, Honduras, Algeria, Tanzania, Kenya, Ethiopia, Djibouti, Congo, Morocco, UAE, Saudi Arabia, Iraq, Singapore, Thailand, Malaysia, Philippines and etc. Our market is mainly in Africa, South America, Middle East, South East Asia and some European countries.
We devote ourselves to provide a wide range of Chinese well-known construction equipment series to fulfill our customer’s different demands for their projects.
