90HP Tractor price China cheap farm Tractor LYH904 4WD for sale
Cheap tractor price list, tractor, farm tractor, tractor truck,mini tractor,tractor parts,hand tractor for sale
Tractor made in china for sale
LYH904 90HP 4x4 farm tractor
WHEELED TRACTOR
CERTIFICATION: ISO&CE
DIESEL POWER: 66.2kw
TRCTION FORCE: 90 horsepower
DRIVE: FRONT+ REAR DRIVE AXLE
This LYH904 Wheeled Tractor is very excellent in following areas:
- Adopt Zhejiang Xinchai diesel engines, better reliability, more back coefficient for torsion;
- 10 inch clutch with double actions;
- Gear-box shows 4×(2+1), namely 8 forwards, 4 returns, exchange in joggle;
- Driving force output device with postposition, peaceful and stable transmission, stronger bear the weight of loading;
- Adopt front-wheel turning with full liquid-pressure and independent oil way, turn agilely, reliably, power-saving;
- Adopt tray-style arrester, stronger brake moment, reliabe brake;
- Adopt semi-separation lifter, plough depth control way is force adjusting, place adjusting, force and place both adjusting;
- The final driving is planet-gear style, smaller volume, bigger decelerating ratio;
- Installed adjustable chair with elasticity and shock absorption, comfortable driving;
- The whole trator is beautiful, taste, modern, fashion
Can option Cabin, Air-conditioner, paddy field tire. Four color optional without adding money. Rear 3 point hitch.
We can also supply all kinds of implements ! If you need,pls contatc us for more details.
Specification of 90HP Tractor price China cheap farm Tractor LYH904 4WD for sale
Type |
LYH900 |
LYH904 |
|
Model |
4*2 (double-wheel driving) |
4*4 (4-wheel driving) |
|
Dimension (mm) |
Length (with front loading) |
4060 |
4396 |
Width |
2038 |
2038 |
|
Height (to vent) |
2810 |
2810 |
|
Wheelbase (mm) |
2195 |
2195 |
|
Front-wheel tread (mm) |
1385~1685 (1485 in common use) |
1610 |
|
Rear wheel tread (mm) |
1620~2020 (1620 in common use) |
||
The smallest ground gap (mm) |
476 |
|
|
Agriculture ground gap (mm) |
396 |
379 |
|
|
Turning radius (m) |
|
5.1 |
5.6 |
not apply the brake with single side |
|
|
|
The whole tractor mass (kg) |
structure mass |
3350 |
3750 |
the smallest using mass |
3100 |
3500 |
|
Loading mass |
front loading |
3590 |
3990 |
rear loading |
3340 |
3740 |
|
Rated traction (KN) |
17.3 |
20.8 |
|
Engine type |
4110T90 |
||
Marked power (KW) |
66.2 |
||
Clutch |
10 inch double action |
||
Gear box |
Shift combination style. Mesh cover shift |
||
Speed range |
2.4-31.9 |
||
Centre turn |
Spire and taper sub-gear |
||
Different speeder |
Double planet wheels, close style |
||
Different speed lock |
Post and pin style |
||
Final transmission |
Planet gear style |
||
Front driving bridge |
Full closed prick gear style (for types with 4- wheel driving ) |
||
Independent driving box |
Column gear with straight teeth (for types with 4-wheel driving ) |
||
Front wheel table specification |
7.5-16 |
11.2-24 |
|
Rear wheel table specification |
13.6-38 |
||
Redirector type |
Mechanical or hydraulic turning |
||
Arrester type |
Arrester with double pieces of oil-bath tray (mechanical style) |
||
Lifter type |
Semi-separation |
||
Control way to plough depth |
Force, place control and floating control |
||
Hanging device type |
Three point hanging with postposition |
||
Driving output axis turning speed (r/min) |
540/760 |
||
Contact way:
Amy Shen
Sales Manager
Shanghai Dobest Construction Machinery Co., Ltd.
Web:
Skype: amyshen1212
Yahoo: amyshen121286
Tel: +86-21-66058291 Fax:+86-21-66058391
Mobile/WhatsApp/Viber/Wechat: +86-13701803469
The warranty covers the Product, for one (1) year from the documented date of purchase.
We promise excellent service under the warranty:
1. We will send the new spare parts by air express, such as DHL or TNT once our customers request an urgent replace of broken parts under warranty
2. We will arrange engineers to service machinery overseas in case our customers are in need help for installation and training, such as tower cranes, concrete batching plant, asphalt mixing plant, stone crushing plant, etc.
3. We will send original spare parts by shipment or air express for option in case our clients want to purchase some other spare parts for repair and regular maintenance of their machines.
As a leading exporter specially for a big variety of construction equipment, Shanghai Dobest Construction Machinery Co., Ltd. is located in China's biggest port city Shanghai, which is also the financial center and business center.
Our mission is to provide a 'one-stop' service to fulfill our customers’ needs and expectations with the high quality product, prompt delivery and perfect service after sales. We promise to do our best to make our customers satisfied as we offer professional construction solutions for their kinds of projects.
By keeping the principle of good quality, competitive price, superior service, now we have won a very good reputation from all of our customers all over the world. Thus, our business expanded rapidly and so far we have exported our products to more than 20 countries and regions, including Australia, New Zealand, Brazil, Argentina, Honduras, Algeria, Tanzania, Kenya, Ethiopia, Djibouti, Congo, Morocco, UAE, Saudi Arabia, Iraq, Singapore, Thailand, Malaysia, Philippines and etc. Our market is mainly in Africa, South America, Middle East, South East Asia and some European countries.
We devote ourselves to provide a wide range of Chinese well-known construction equipment series to fulfill our customer’s different demands for their projects.
