Help CenterTractor TY304
US$ 3,500 - 5,000
MOQ: 10 Sets
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Wheel Tractor, Wheel tractor
By wheel:
4WD
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TY304 Tractor With Power Steering,4WD,dual Stage Clutch,4 Cylinders EngineUS$ 2,100 - 2,900MOQ: 10 Sets -
Tractor TY254 With 4WD ,implements Can be Fitted With.famous Brand EnginUS$ 2,100 - 2,900MOQ: 10 Sets
-
Garden Tractor 250,25hp ,2WD .fitted With Kinds of ImplementsUS$ 2,000 - 30,000MOQ: 1 Set
-
Farm Tractor 350US$ 2,000 - 3,000MOQ: 1 Unit
-
Tractor TY254 With 4WD ,with Fotony Type Engine Hood,famous EngineUS$ 2,600 - 3,900MOQ: 10 Sets
Condition
New
Type
Other, Wheel Tractor, Wheel tractor
By wheel
4WD
Usage
Farm Tractor
Certificate
Other, CQC
Brand Name
haotian
Model Number
TY304, TY
Place of Origin
Shandong, China
Specifications
Tractor1) high transmission efficiency
2) high traction,high adaptability
3) easy start
4)low tremble
Tractor
This series product is a middle and small hp tractor directly connected with its engine. It has the characteristics of high transmission efficiency, low tremble, high traction, high adaptability and easy start, it is the upgraded generation shift product. Jaw type differential lock can improve the pass-ability. Hydraulic output interface can make direct connection with the dump trailer. This series tractor can have many different configurations according to customers demands: single stage clutch or two stage clutch, (3+1) ×2 six shifts or (4+1) ×2 eight shifts in which the creeping shift can be selected, one or two standard PTO rev., fixed or adjusted tread, back catalogue 0 or 1 suspensions.
| Main Technical Specifications | |||||||||
| Model | TY180 | TY200 | TY220 | TY240 | TY250 | TY280 | TY300 | ||
| Type | 4×2 2WD | ||||||||
| Length | 2630/2707 | 2654/2767 | |||||||
| Width | 1296/1596 | ||||||||
| Depth | 1338/1388 | 1365/1414 | |||||||
| mm | Wheel base | Front wheel | 950 or 1270fixed or 970~1270 adjustable | ||||||
| Main Dimensions of Tractors | Rear wheel | 1300 fixed or 1000~1300 adjustable | |||||||
| Tread | 1465/1559 | ||||||||
| Min. Ground Base | 320 | 330 | |||||||
| kgDry Mass | 900/1040 | 980/1060 | 1010-1060 | ||||||
| Engine | Model | 290/295 | 295 | 295 | 2100 | 2102 | |||
| Type | Vertical, 2-cylinder, Water Cooled and 4-stroke | ||||||||
| (kw) | 13.2 | 14.72 | 16.1 | 17.65 | 18.4 | 20.6 | 22.06 | ||
| Rated Power | |||||||||
| Rated rev.(r/min) | 2200 | 2300 | 2400/2500 | 2400 | |||||
| Fuel | Diesel Oil | ||||||||
| Tyre | Front tyre | 4.00-16 | 4.50-16/5.00-16 | ||||||
| Rear tyre | 8.3-24 | 9.5-24 | |||||||
| Clutch | Dry-friction, Single Stage or Dry-friction, Two Stage | ||||||||
| Steering | Mechanical Type | ||||||||
| Gearbox | (3+1)×2 or (4+1)×2 or (4+1)×2×2 (with creeper) | ||||||||
| Suspension Type | Post Postitioned Tri-point Suspension Catalogue O | Post Postitioned Tri-point Suspension Catalogue O or I | |||||||
| Type and Rev(r/min) | Non-independent Type 540 or Non-independent Type 540/1000, 540/720 or Semi-independent Type 540/1000,540/720 | ||||||||
| PTO Shaft | |||||||||
| Spline | I35 Rectangle Spline with 6 teeth6×28.91×34.79×8.69 | ||||||||
