Tractor
Greenhouse-King Series tractors are designed for greenhouses and gardens specially. It is directly connected with double-cylinder engine. It has jaw type differential lock, single-side brake and dual-speed PTO. The outside is low, short and narrow, so it has compact structure and small radius of turning circle. The oversize even is smaller than single-engine tractor. When work in ordinary greenhouses, it can plough freely without dead angle. Their depth of plough and degree of rotary smash are better than ordinary single-engine four-wheeled tractor of farm managing machine. The working efficiency is high and the working quality is good. With different implements, the tractor can accomplish different kinds of works, such as plough, fertilization, crushing, spray, etc. in vegetable and flower greenhouses or gardens. And also, this tractor has all the other functions as other tractors. It is an ideal machine for greenhouses and gardens.
Main technical specifications |
Model |
TY304 |
Type |
4×4 Wheeled Type |
Dimensions of tractor(mm)
|
Length |
2430 |
Width |
1230 |
Height |
1070 |
|
Front Wheel |
960 |
Tread |
Rear Wheel |
980 |
Wheel base |
1473 |
Min. Ground Clearance |
277 |
One-sideBraking |
2.4 |
Min. Radius of Turning Circle(m) |
No braking |
2.8 |
Dry Mass(kg) |
900 |
Engine |
Model |
3T30 |
Type |
3-cylinder, Vertical, Water Cooled and 4-stroke |
Rated Power(KW) |
22.1 |
Rated Rev.(r/min) |
2400 |
Fuel |
Diesel |
Connection between engine and clutch |
Shaft connection |
Clutch |
Single Disc, Dry-Fricyion, Single Stage |
Transmission Box |
(3+1)×2 or (4+1)×2 Mechanical Type |
Steering |
mechanical Type |
Suspension Type |
Post positioned Tri-point Suspension, Catalogue O |
PTO |
Type and Rev.(r/min) |
Single speed non-independent type 540 or double speed Non-independent 540/1000 |
Spline Size(mm) |
Post positioned I35 Rectangle Spline with 6 teeth(6×28.91×34.79×8.69) |
Structure and specifications are subject to change without notice. |
||||||||||||||||||||||||||||||||||||
