BOMR FIAT Gearbox Tractor (350 1 Pair Hydraulic Output)

BOMR FIAT Gearbox Tractor (350 1 Pair Hydraulic Output) thumbnail-1
BOMR FIAT Gearbox Tractor (350 1 Pair Hydraulic Output) photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Luoyang Boma Agricultural Engineering Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 2WD
Usage Farm Tractor
Certificate EPA
Brand Name BOMR
Model Number 350
Place of Origin Henan, China

Specifications

1. 8+2 shuttle shift
2. Italy fiat chassis
3. Increase 30% efficiency
4.Save 25% of fule

BOMR FIAT Gearbox tractor (350 1 pair hydraulic output)BOMR FIAT Gearbox tractor (350 1 pair hydraulic output)BOMR FIAT Gearbox tractor (350 1 pair hydraulic output)BOMR FIAT Gearbox tractor (350 1 pair hydraulic output)BOMR FIAT Gearbox tractor (350 1 pair hydraulic output)BOMR FIAT Gearbox tractor (350 1 pair hydraulic output)

1, The lowest ground clearance is 550-600mm, suitable for operation in tobacco or cotton field.

2,Streamline covers offers great appearance.

3,  Chasis is heavier than similar models with more safety and reliability in travel.

4,  Front wheel pump will not affect tool operation in changing gear, satisfying farm land operation requirement.

5,  Wet disk brake is smooth and reliable with long service life.

6,  Maintenance free battery well positioned is installed for more convenient use and removal.

7,  With 10%-27% higher speed than similar models, it offers higher efficiency in transport and fuel saving

8,  Bolt type differential lock will effectively prevent side sliding going on slope or operation in rainy days with superb mobility.

9,  Space between font and back wheels is adjustable to adopt for farming requirement in different area.

10,The engine has pressure reducing mechanism to enable easy start up in cold winter.

11,Water tank has a large surface for radiation without boiling.

The main specification of bomr 30hp to 35hp tractor
Tractor Model 300 304 350 354
General Specification Driver Type 4×2 4×4 4×2 4×4
Length*width*Height(mm) 3545*1488*1922 3545*1488*1923 3545*1488*1924 3545*1488*1925
Traction force(KN) 6.2 7.5 7.9 9.48
Steering Machanical hydraulic Machanical hydraulic
Wheel base(mm) 1634 1675 1755 1799
Front wheel tread(mm) 1172-1472 1200 1172-1472 1200
Rear wheel tread(mm) 1148-1448 1148-1448 1148-1448 1148-1448
P.T.O.Max.Power(Kw) 18.8 18.8 21.8 21.8
Ground clearance(mm) 320 260 360 280
Engine Type SL2105ABT2 SL2105ABT2 SL3100ABT2 SL3100ABT2
Bore×Stroke(mm) 105*117 105*117 100*117 100*117
Rated revolution (r/min) 2300 2300 2300 2300
Max.torque(n.m) ≥114.2 ≥114.2 ≥131.8 ≥131.8
Speed of Max.torque r.p.m. ≤11725 ≤11725 ≤11725 ≤11725
Transmission Clutch Single-stage clutch
Gear box 8F+2R
Working device Lifter tilling depth control Power,bit-conditioning
Max.lifting capacity( KN ) 5 5 5.8 5.8
Suspension type Class 1  3-Point hitch
Speed of P.T.O.(r/min) stardard:540/720;optional:540/1000,720/1000
Notice:All above parameters are subject to change without notice because of rapid development of products.
