BOMR FIAT Gearbox Hydraulic Agricultural Tractor (854 Swing Traction)

BOMR FIAT Gearbox Hydraulic Agricultural Tractor (854 Swing Traction) thumbnail-1
BOMR FIAT Gearbox Hydraulic Agricultural Tractor (854 Swing Traction) photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Luoyang Boma Agricultural Engineering Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Certificate Other
Brand Name BOMR
Model Number BOMR 854
Place of Origin Henan, China

Specifications

1. 12+12 shuttle shift
2. Turbo charge
3. Italy fiat chassis
4. Increase 30% efficiency
5. Save 25% of fule





The characteristic of tractor from 70hp to 100hp



  1. Our tractors have YTO or Quanchai engine; the engine has the strong power and high quality.
  2. Gearbox has 12 forward shifts and 4 reverse shifts.
  3. The side shift control made the shifting more comfortable and humanistic.
  4. Gearbox and rear axle use engagement sleeve shift. Shifting flexibly and stably, never neutral
  5. Hydraulic steering system has independent oil circuit.
  6. Independent PTO shaft has so many speed of rotation to choose. For example, 540/760/850/1000. It can meet customer’s different requirements when using tractor in the farm.
  7. Pedal operated hydraulic driving brake system and hand shank operated mechanical parking brake system, made the brake system is safety and reliable.
  8. Force buried lifter (force, position comprehensive control and floating control) is using reliably and mending conveniently. Hydraulic system use oil separate structure, which has strong lifting capacity. It matches with many large agricultural implements.
  9. 1 or 2 pair hydraulic outputs can be chose. And air-brake can be chose.



 10.   Use 4 planetary wheeled differential, transmission stably and reliably.



 11.   Our tractor adopt underneath double diesel tank. The diesel tank’s volume is large, which reaches 150L. And it is satisfied with using tractors for long-time.



 12.   Reinforced 3 point-suspension postposition is stronger, using reliable and long life. The bottom tie rod can float





BOMR FIAT Gearbox hydraulic agricultural tractor (854 Swing traction)BOMR FIAT Gearbox hydraulic agricultural tractor (854 Swing traction)

BOMR FIAT Gearbox hydraulic agricultural tractor (854 Swing traction)BOMR FIAT Gearbox hydraulic agricultural tractor (854 Swing traction)BOMR FIAT Gearbox hydraulic agricultural tractor (854 Swing traction)

BOMR FIAT Gearbox hydraulic agricultural tractor (854 Swing traction)BOMR FIAT Gearbox hydraulic agricultural tractor (854 Swing traction)



The Main Specification of Bomr 80hp tractor
Tractor Model BOMR800 BOMR804 BOMR850 BOMR854
General Specification Driver Type 4×2 4×4 4×2 4×4
Length×width×Height(mm) 4520×1885×2450 4520×2170×2530 4520×1885×2450 4520×2170×2530
Traction force(KN) 14.9 17.6 15.5 18.7
Steering Hydraulic  Hydraulic  Hydraulic  Hydraulic
Wheel base(mm) 2342 or 2353 2314 or 2325 2342 or 2353 2314 or 2325
Front wheel tread(mm) 1400-1900 1630-1960 1400-1900 1630-1960
Rear wheel tread(mm) 1500-2100 1520-2120 1500-2100 1520-2120
P.T.O.Max.Power(Kw) 53.1 53.1 56.3 56.3
Ground clearance(mm) 360 430 360 440
Engine Type 4JR3AT80X 4JR3AT80X 4JR3AT85X 4JR3AT85X
Bore×Stroke(mm) 108×135 108×135 108×135 108×135
Rated revolution (r/min) 2200 2200 2400 2400
Max.torque(n.m) 280 280 280 280
Speed of Max.torque r.p.m. 1500-1700 1500-1700 1500-1700 1500-1700
Transmission Clutch Dual-stage clutch
Gear box 12F+4R
Working device Hydraulic lifter tilling depth control Forced buried
Max.lifting capacity(KN) 14.2 14.2 15 15
Suspension type Class 2  3-Point hitch
Speed of P.T.O.(r/min) stardard;540/720;optional:540/1000,720/1000
Notice:All above parameters are subject to change without notice because of rapid development of products.
