BOMR FIAT Gearbox YTO Engine Agricultural Diesel Tractor (1304 Hydraulic Output)

BOMR FIAT Gearbox YTO Engine Agricultural Diesel Tractor (1304 Hydraulic Output) thumbnail-1
BOMR FIAT Gearbox YTO Engine Agricultural Diesel Tractor (1304 Hydraulic Output) photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Luoyang Boma Agricultural Engineering Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Certificate EPA
Brand Name BOMR
Model Number BOMR 1304
Place of Origin Henan, China

Specifications

1. 12+4 shift gearbox
2. Turbo charge
3. Italy fiat chassis
4. Increase 30% efficiency
5. Save 25% of fule



The characteristic of tractor from 110hp to 130hp



  1. YTO engine, the engine has the strong power and high quality.
  2. Gearbox has 12 forward shifts and 4 reverse shifts.
  3. Gearbox and rear axle use engagement sleeve shift. Shifting flexibly and stably, never neutral
  4. Hydraulic steering system has independent oil circuit.
  5. Independent PTO shaft has so many speed of rotation to choose. For example, 540/760/850/1000. It can meet customer’s different requirements when using tractor in the farm.
  6. Pedal operated hydraulic driving brake system and hand shank operated mechanical parking brake system, made the brake system is safety and reliable.
  7. Force buried lifter (force, position comprehensive control and floating control) is using reliably and mending conveniently. Hydraulic system use oil separate structure, which has strong lifting capacity. It matches with many large agricultural implements.
  8. 1 or 2 pair hydraulic outputs can be chose. And air-brake can be chose.
  9. Use 4 planetary wheeled differential, transmission stably and reliably.



 10.   Our tractor adopt underneath abnormal fuel tank. The tank’s volume is large. It reaches 230L. And it is satisfied with using tractors for long-time.



 11.   Reinforced 3 point-suspension postposition is stronger, using reliable and long life. The bottom tie rod can float



The Main Specification of Bomr 110hp to 130hp tractor
Tractor Model 1104 1204 1254 1304
General Specification Driver Type 4×4 4×4 4×4 4×4
Length×width×Height(mm) 5015×2335×2970 5015×2335×2970 5015×2335×2970 5015×2335×2970
Traction force(KN) 26 27 29 32
Steering hydraulic hydraulic hydraulic hydraulic
Wheel base(mm) 2688.5 2688.5 2688.5 2688.5
Front wheel tread(mm) 1672-2003(1760) 1672-2003(1760) 1822-2153(1910) 1822-2153(1910)
Rear wheel tread(mm) 1662-2262(1862) 1662-2262(1862) 1662-2262(1862) 1662-2262(1862)
P.T.O.Max.Power(Kw) 71.25 71.25 81.7 81.7
Ground clearance(mm) 465 465 465 465
Engine Type YTO 110HP YTO 110HP YTO 110HP YTO 110HP
Bore×Stroke(mm) 108×125 108×125 110×135 110×135
Rated revolution (r/min) 2300 2300 2300 2300
Max.torque(n.m) ≥282 ≥340 ≥350 ≥370
Speed of Max.torque r.p.m. 1700-1800 1700-1800 1600-1800 1600-1800
Transmission Clutch Dual-stage clutch
Gear box 12F+4R
Working device Lifter tilling depth control Height adjustable, floating control
Max.lifting capacity( KN ) ≥28
Suspension type Class 2  3-Point hitch
Speed of P.T.O.(r/min) stardard:760/1000;optional:540/760,540/1000
Notice:All above parameters are subject to change without notice because of rapid development of products.
