ATV 2014 With EEC,quad,4x4 .farm ATV 500cc Extend Model
Specifications
500cc ATVEPA / EEC
Single-cylinder, water-cooled
4-Stroke
Steel bottom plate,Aluminum rim,Aluminum A-swing arm
| 500CC Specification | |||
| No. | Category | Data | |
| 1 | ATV | L×W×H,mm | 2250x1150x1200 |
| 2 | Wheelbase,mm | 1460 | |
| 3 | Tread,mm | Ft920,Rr880 | |
| 4 | Min. Clearance,mm | 230 | |
| 5 | Min. Turning Radius,mm | ≤4800 | |
| 6 | Handlebar swing angle,(°) | 30±3 | |
| 7 | Net Weight,kg | 360 | |
| 8 | Loading Capacity,kg | 220 | |
| 9 | Top Speed,km/h | 120 | |
| 10 | Brake System(Ft/Rr) | Linkage Disc Brake | |
| 11 | Brake Operation(Ft/Rr) | Hand & Foot brake | |
| 12 | Rim(Ft/Rr) | Alloy Wheel Rim | |
| 13 | Tyre(Ft/Rr) | Ft:26x9-12,Rr:26x11-12 | |
| 14 | Tyre Pressure(Ft/Rr),kPa | 150 | |
| 15 | Transmission | Shaft Drive | |
| ENGINE | |||
| 18 | Type | Single Cylinder,4-Stroke,Water-cooled,4-Valve | |
| 20 | Bore×Stroke,mm | 100x84 | |
| 21 | Cylinder Volume,ml | 659.4 | |
| 22 | Compression Ratio | 10.2:1 | |
| 23 | Rated Power/Rev,kw(r/min) | 30/550 | |
| 24 | Maximum Net Power/Rev,kw(r/min) | 32/5800 | |
| 25 | Maximum Torque/Rev,kw(r/min) | 56/5000 | |
| 26 | Min. Fuel Consumption Rate,g/(kw.h) | 270 | |
| 27 | Min Steady Rev with No-Load,r/min | 1500 | |
| 28 | Fuel Type | No.93 Unleaded Petrol | |
| 29 | Lubrication | Pressure/Splash | |
| 30 | Lubricating Oil | SF15W-40 | |
| 31 | Clutch | Automatic Centrifugal | |
| 32 | Start Mode | Electric | |
| 33 | Ignition | DC-CDI | |
| 34 | Carburettor | Vacuum Diaphragm | |
| 35 | Spark Plug | K6RTC | |
| 36 | Battery | GT20-4 | |
| 37 | Headlight | 12V 35Wx2 | |
