US$ 3,000 - 60,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Other, 1000CC
Certificate:
Other, EEC,EPA
Fuel:
Gas / Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
150CC Mini Youth UTV 150cc UtvNegotiableMOQ: 1 Set -
150cc Utv With EpaUS$ 1,000 - 1,500MOQ: 1 Set
-
1100cc Jeep 4x4US$ 9,000 - 11,000MOQ: 1 Piece
-
JEEP UTV 800cc 4x4 4x2 EEC Truck 4x4 Utv Suspension Cheap go Karts for Sale 800cc JeepUS$ 6,000 - 6,300MOQ: 1 Set
-
150CC Mini Youth UTVNegotiableMOQ: 1 Set
Type
Other, 1000CC
Certificate
Other, EEC,EPA
Fuel
Gas / Diesel
Transmission Type
Automatic
Place of Origin
Shandong, China
Model Number
UTV1000cc
Specifications
- Water-cooled EFI Engine- Shaft Drive 2WD/4WD
- F/R Locking Differential
- Manual Clutch 5-Speed.
| Specification | |
| Model name | SG970-3 |
| Engine type | Four-cylinder inline, four stroke, water cooled, ,SOHC,EFI |
| Displacement | 1000cc |
| Bore×stroke | 65.5×72mm(2.6×2.8in) |
| Compression ratio | 8.8:1 |
| Ignition | EFI-DELPHI |
| Cooling system | Water-cooled |
| Starting system | Electric |
| Vehicle dimension(L×W×H) | 3450×1700×1860mm(135.8×66.9×73.2in) |
| Cargo bed(L×W×H) | 1205×1420×310mm(47.4×55.9×12.2in) |
| Wheelbase | 2300mm(90.6in) |
| Front tread | 1290mm(50.8in) |
| Rear tread | 1290mm(50.8in) |
| Ground clearance | 350mm(13.8in) |
| Seat height | 850mm(33.5in) |
| Dry weight | 730kgs(1607.9lbs) |
| Fuel capacity | 25L(94.6gal) |
| Cargo bed load capability | 300kgs(660.8lbs) |
| Towing capability | 5330N(1200lbf/543kgf) |
| Final Drive | Shaft, SELECTABLE 4×4 |
| Brake system front/rear | Disk/Disk |
| Suspension | Independent double wishbone |
| Steering | Rack&pinion |
| Front tyre size | 26×12-12 |
| Front wheel size | 12×9 |
| Rear tyre size | 26×12-12 |
| Rear wheel size | 12×9 |
| Top speed | 90km/h(56MPH) |
| Loading information | 2 units/20″;6 units/40HQ |
| Packing Size | 3570×1770×1130mm(140.6×69.7×44.5in) |
| Waterproof | 0.5m(19.7in) |
| Max climbing gradient | 30° |
| Min opernation temperature | -40°C(-40°F) |
| Max opernation temperature | 40°C(104°F) |
| Max torque and rotate speed | 74N.m/3000-3500rpm |
| Rated power and rotate speed | 35.5kw/5300rpm |
