| Engine type | 4-stroke,Single-Cylinder, Air/Oil-cooled | ||||||
| Engine style | GY6 style | ||||||
| Displacement | 202cc | ||||||
| Horse Power | 8.5kw(7000r/min) 11.8HP | ||||||
| Valve Configuration | OHV | ||||||
| Compression ratio | 10.3:1 | ||||||
| FUEL SYSTEM | |||||||
| Fuel Delivery System | Fuel Pump+Vacuum Diaphragm Carburetor | ||||||
| Choke System | Automatic | ||||||
| Fuel capacity | 9.5L (2.1 Gallon) | ||||||
| Fuel meter | LED Fuel Meter | ||||||
| DRIVETRAIN | |||||||
| Driveline Type | 2X4 | ||||||
| Final Drive | Shaft-Drive | ||||||
| Transmission | Constantly Variable Transmission | ||||||
| Gear Selection | R-N-D | ||||||
| Speed meter | LED Speed Meter | ||||||
| ELECTRICAL SYSTEM | |||||||
| Forward Lights | High & Low Beam | ||||||
| Heading Light | LED | ||||||
| Driving Light | LED | ||||||
| Rear Lights | Brake Lights & Left/Right Signal lights | ||||||
| Starting system | Electric start | ||||||
| Ignition system | D.C.D.I | ||||||
| SUSPENSION / BRAKES | |||||||
| Suspension Front | Double A-arm Suspension | ||||||
| Suspension Rear | Fang power 4-Link® bar Rear Suspension | ||||||
| Brakes Front | Front Dual Hydraulic Disk | ||||||
| Brakes Rear | Rear Dual Hydraulic Disk | ||||||
| TIRES | |||||||
| Front Tread | 1150mm ( 45.3 in) | ||||||
| Rear Tread | 1040mm ( 41in) | ||||||
| Front & Rear tire size | 25x8-12 / 25x10-12 | ||||||
| Front & Rear rim size(Alloy) | 12x6 / 12x8 | ||||||
| MISC | |||||||
| Manufacturers Defect Warranty | 6 Months | ||||||
| Top speed | 60km/h | ||||||
| Dry weight | 340kg ( 750lbs.) | ||||||
| Gross weight | 348kgs(766lbs) | ||||||
| Wheelbase | 1980mm (78in) | ||||||
| Vehicle dimension (L×W×H) (Heading Light Height included) | 2590x1350x1660mm (102x 53x65.4 in) | ||||||
| Ground clearance | 260mm (10.2in) | ||||||
| Safety | Driver & Passenger Triple Point Fix Seat Belts/ Metal Semi-Door | ||||||
