PE or PVDF Coated Aluminum Coil

PE or PVDF Coated Aluminum Coil

01) Alloy: A3003 A1100 A8011 etc

02) Aluminum thickness: 0.026mm~1.20mm

03) Aluminum max width:1600mm

Standard width: 1240mm

Special width such as 1300mm, 1520mm, 1570mm, 1595mm are also available

04) Coil's standard diameter: 1200mm

Interior diameter:150mm,405mm or 505mm

05) weight: 2.5T/coil 3.0 T/coil

06) Coating finish: PVDF, POLYESTER, ACRYLIC

07) Gloss: meet the customer requirement

08) Total coating thickness:

PVDF coating: more than 25 micron

Polyester coating: more than 18 micron

09) Coating hardness (pencil hardness) more than 2H

10) coating adhesive : no lower than first grade

11) Impact resistance: No cracking and peeling (50kg/cm ,ASTMD-2794:1993)

12) Flexibility (T-bend): 2T

13) MEK resistance: more than 100

14) Bottom side aluminum sheet is coated with protective polyester material, thickness more than 6 micron

15) outer packing ;export standard ,  wooden plate .
