1.6 Ton Electric Power Stacker DC Power, Lifting height 3m, ERC115
- 300 Unit / Units per Month
- Shanghai
- T/T Credit Card
- BENE 45 ton reach stacker 45ton container lift truck with Cummins VOLVO engine DANA transmission
- 45ton Container reach stacker provider vs Linde Hyster 45ton container stacker price
- Chinese 40ton forklift BENE 40 ton container tippler for 20ft container loading and unloading material
- Fanuc robot M-20iA range 1811mm load 20kg cutting manipulator intelligent sorting machine
- Chinese BENE 40ton to 42ton fork loader for 24ft container lifting 42ton container tippler
- Chinese container reach stacker manufacturer vs Sany 45ton container lift truck Hyster 45 ton container stacker price
Product Details
Condition: | New | Place of Origin: | Shanghai, China | Brand Name: | GP |
Model Number: | ERC116 | Dimension(L*W*H): | 1940*850*1465mm | Certification: | CE, SGS |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.6 Ton Electric Power Stacker DC Power1. Lifting height 3m
2. Low noise, no pollution
3.Curtis , Itaian ZAPI/SME cotroller
1.6 Ton Electric Power Stacker DC Power for materials handling, Lifting height 1.6m-4.5m,with nice design.
Advantge of electric stacker
1.Conforms To The Standards Of En1726-1:1999and En1175-1:1998
2.High Stability And Flexible Operation
3.Smooth stepless speed control from CURTIS
4.Low Noise, No Pollution, And High Reliability
5. Power unit and drive wheel made in Europe
6. Large Capacity Battery Makes The Stacker Work Longer
7.Top-Quality Control System - CURTIS from USA or ZAPI / SME from Italia
Specifications
FULL ELECTRIC STACKER | Model | |||||||
Item | Specification | Unit | ERC112 | ERC115 | ERC116 | ERC118 | ERC120 | |
1 | General | Rated capacity | Kg | 1200 | 1500 | 1600 | 1800 | 2000 |
2 | Load center | mm | 600 | 600 | 600 | 600 | 600 | |
3 | Drive type | Standed | ||||||
4 | Motor brake | Electromagnetic | ||||||
5 | Load distance (centerline of front axle to front face of forks) | 716 | 716 | 716 | 716 | 716 | ||
6 | Battery weight | Kg | 200 | 200 | 200 | 280 | 280 | |
7 | Self weight | Kg | 1080 | 1105 | 1130 | 1250 | 1280 | |
8 | Full Load per Axle - Driving side / bearing side | 865/215 | 885/220 | 905/225 | 1000/250 | 1025/255 | ||
9 | Empty Load per Axle - Driving side / bearing side | Kg | 970/1310 | 1110/1495 | 1095/1635 | 1300/1750 | 1400/1880 | |
10 | Dimensions | Lifting Height (standard) | mm | 3000 | ||||
11 | Fork min. ground clearance | mm | 85 | |||||
12 | Adjust width of fork (standard) | mm | 570 | |||||
13 | Fork size | mm | 60/180/1150 | |||||
14 | Minimum ground clearance | mm | 25 | |||||
15 | Overall length | mm | 1940 | 1940 | 1940 | 1970 | 1970 | |
16 | Overall width | mm | 850 | 1050 | ||||
17 | Overall height (including handle ) | mm | 1465 | 1465 | 1465 | 1465 | 1465 | |
18 | Bodywork height | mm | 845 | 845 | 845 | 845 | 845 | |
19 | Overall height mast raised | mm | 3530 | 3530 | 3530 | 3530 | 3530 | |
20 | Overall height mast lowered | mm | 2055 | 2055 | 2055 | 2055 | 2055 | |
21 | Front wheel tread | mm | 390 | 390 | 390 | 390 | 390 | |
22 | Supporting wheel tread | mm | 708 | 708 | 708 | 800 | 800 | |
23 | Minimum turning radius | mm | 1630 | 1630 | 1630 | 1630 | 1630 | |
24 | Stacking right angle aisle width | mm | 2236 | 2236 | 2236 | 2270 | 2270 | |
25 | Perfor-mance | Max. driving speed full/empty | Km/h | 5/6 | 5/6 | 5/6 | 5/5.8 | 5/5.5 |
26 | Max. lifting speed full/empty | mm/s | 110/130 | 95/130 | 90/130 | 80/120 | 80/120 | |
27 | Max. declining speed full/empty | mm/s | 120/110 | 110/100 | 110/90 | 80/90 | 80/90 | |
28 | Grade ability full/empty | % | 5/8 | 5/8 | 5/8 | 5/8 | 5/8 | |
29 | Wheel | Wheels material | Polyurethane | |||||
30 | Wheel number (front/rear) | 4/3 | ||||||
31 | Drive wheel (mm) | φ252x87 | φ252x87 | φ252x87 | φ252x87 | φ252x87 | ||
32 | Load wheel (mm) | φ80x70 | φ80x70 | φ80x70 | φ80x70 | φ80x70 | ||
33 | Balance wheel (mm) | φ150x48 | φ150x48 | φ150x48 | φ150x48 | φ150x48 | ||
34 | Wheelbase | 1295 | 1295 | 1295 | 1295 | 1295 | ||
35 | Power and Control | Travel motor | KW | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 |
36 | Lift motor | KW | 2.2 | 3 | 3 | 3 | 3 | |
37 | Voltage | V | 24 | 24 | 24 | 24 | 24 | |
38 | Battery capacity | Ah | 210 | 210 | 210 | 280 | 280 | |
39 | Control system | CURTIS / ZAPI / SME | ||||||
40 | Sound level at the driver's ear acc. to EN12053 | dB/(A) | 67 |
