Home > Auto, Motorcycle Parts & Accessories > Vehicle Repair Equipment & Tools > Other Auto Repair Equipment & Tools > Solid Tyre Press

Solid Tyre Press

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Model Number:

TP80/120/160/200

Contact Supplier Request Quote Chat Now

Shanghai Gather Power Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Model Number TP80/120/160/200

Specifications

Tyre press 80t/120t/160t/200t; Tooling, Provide two kinds of tooling for option, One is for 2-piece & 4-piece rim tyre

Heavy-duty frame, The construction is welded by large-scale I beam and channel beam
High-grade Hydraulic Cylinder, The piston rod is grinded and hard-chromium plated
Compact Hydraulic Power Unit, First level quality in the area
Compact Hydraulic Power Unit, First level quality in the area
Operation Panel, Operated by a handle for Down/Up, Any position can be stopped when the handle released
Tooling, Provide two kinds of tooling for option, One is for 2-piece & 4-piece rim tyre
Easy service &Heavy durability

Tyre Press / Model	Unit	TP80	TP120	TP160	TP200
Maximum pressure	Ton	80	120	160	200
Maximum size of wheel rims	mm	381	508	508	508
Overall length	mm	1640	2090	2090	2090
Overall width	mm	700	850	850	850
Overall height	mm	2170	2210	2210	2210
Intensity of pressure for operation	mpa	21	25	33	33
Oil cylinder stroke	mm	400	400	400	400
fuel tank volume	mm	30	30	30	30
Motor	kw	5.5	5.5	7.5	11
Self-Weight	kg	1100	1510	1610	2110

l Tooling for 2-piece rim tyre
Tyre	Max Tyre Dimension (mm)	Cage (pcs)	Pusher Ring (pcs)	Flange Ring (pcs)
TOOL-II	508	4	11	6

l Tooling for 3-piece & 4-piece rim tyre
Tyre	Max Tyre Dimension (mm)	Cage (pcs)	Pusher Ring (pcs)	Cone (pcs)	Base Plate (pcs)
TOOL-IV	508	6	6	6	3
