1.5-2.5T Self-propelled Electric Pallet Truck

1.5-2.5T Self-propelled Electric Pallet Truck thumbnail-1
1.5-2.5T Self-propelled Electric Pallet Truck photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
GP
Model Number:
ERE
Lift Drive / Actuation:
Electric Motor
Contact Supplier Request Quote Chat Now
Shanghai Gather Power Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GP
Model Number ERE
Lift Drive / Actuation Electric Motor

Specifications

1. Imported hydraulic pump station
2. Compact structure, solid carriage and large capacity
3. Large capacity battery

FULL ELECTRIC PALLET TRUCK
Item   Specification Unit ERE15 ERE20 ERE22 ERE25
1 General Rated capacity Kg 1500 2000 2200 2500
2 Load center mm 600 600 600 600
3 Drive type   Walkie/Standed/Seated
4 Motor brake   Electromagnetic
  Load distance (centerline of front axle to front face of forks) mm 963/1054 963/1033 963/1033 957
5 Battery weight Kg 48 185 185 280
  Self weight (with battery) Kg 286 520 515 970
  Full Load per Axle - Driving side / bearing side Kg 675/1115 1040/1480 1085/1630 162/1850
6 Empty Load per Axle - Driving side / bearing side Kg 230/60 405/115 400/115 780/200
7 Dimensions Lifting Height (standard) mm 120 120 120 130
8 Fork min. ground clearance mm 85 85 85 85
9 Adjust width of fork (standard) mm 520/650 540/685 540/685 560
10 Fork size mm 47/160/1220 60/160/1150 60/160/1150 60/160/1150
12 Minimum ground clearance mm 24 25 25 25
13 Overall length mm 1660 1815/1885 1815/1885 2025
14 Overall width mm 700 726 726 796
15 Overall height (including handle ) mm 1235 1323 1323 1290
17 Bodywork height mm 677 745 745 1196
19 Wheel tread (front/rear) mm 490/490 540/380 540/380 441/380
20 Supporting wheel tread mm 1310 1368 1368 1515
22 Minimum turning radius mm 1976 1640 1640/1710 1865
23 Stacking right angle aisle width (1200mm pallet) mm 1976 2105 2105 2255
24 Performance Max. driving speed (full) Km/h 5 5 5.8 8.7
25 Max. driving speed (empty) Km/h 5.2 5.2 6 9
26 Max. lifting speed (full) mm/s 27 27 19 33.7
27 Max. lifting speed (empty) mm/s 35 35 38 45
28 Max. declining speed (full) mm/s 42 42 30 35.7
29 Max. declining speed (empty) mm/s 27 27 27 18.7
30 Grade ability full/empty % 5/8 10/16 9/15 6.9/14
  Steering angle ° 205 180 180 180
31 Sound level at the driver's ear dB(A) <70 <70 <70 <70
32 Wheel Wheels material   (Polyurethane)
33 Wheel number (front/rear)   4/3
35 Drive wheel (mm) mm φ252X89 φ230X75 φ230X75 φ254X82
36 Load wheel (mm) mm φ74X70 φ74X70 φ84X70 φ84X70
37 Balance wheel (mm) mm φ100X40 φ100X40 φ100X40 φ149X55
39 Power and Control Travel motor KW 0.8 1.5 1.5 2.2
40 Lift motor KW 0.6 0.8 0.8 2.2
41 Voltage V 2X12 24 24 24
42 Battery capacity Ah 80 210 210 360
43 Power   Electric
*——J Walkie;R Standed;S Seated
....
