Electric Stacker With Fork Reach Height 3m

Shanghai Gather Power Industry Co., Ltd.

US$ 1 - 500 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shanghai, China

Brand Name GP

Model Number ERC215

Dimension(L*W*H) 1847*800*1600mm

Certification CE

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

electric stacker
1. Load capacity: 1500KG
2. Drive unit: Battery
3.EURO III
4. CE SGS

electric stacker with fork reach height 3m

Advantage:

1.Durable and rigid frame construction ensure the stackers to handle heavy loads.

2.Hourmeter and BDI(Battery Discharge Indicator)on time informs the operator of recharge requirements.

3.Sideway battery exchange to reduce intervals,ensure working efficiency and productivity.

4.Tilter head ergonomically designed for maximum opertor comfortable,and control buttons positioned to allow operation with either hand.

5.limit switch mounted on top of mast to precisely set the max.Lifting height,avoid any risk of lifting motor overload.

6.Robust and rigid mast configuration optimize stackers lifting stability and safety.

Specification

Manufacturer		GP	GP
Model designation		ERC212	ERC215
Drive unit		Battery	Battery
Operator type		Pedestrian	Pedestrian
Load capacity	Q (kg)	1200	1500
Service weight (Incl. battery)	kg	1080	1105
Tyre type		PU/ PU	PU/ PU
Height, mast lowered	h1 (mm)	1302	1302
Free lift	h2 (mm)	100	100
Lift height	h3 (mm)	1600	1600
Initial lift	h5 (mm)	125	125
Overall length	l1 (mm)	1847	1847
Overall width	b1/ b2 (mm)	800	800
Fork dimensions	s/ e/ l (mm)	60/ 190/ 1150	60/ 190/ 1150
Aisle width, 1000×1200 pallet crossways	Ast (mm)	2400	2400
Aisle width, 800×1200 pallet lengthways	Ast (mm)	2263	2263
Outer turning radius	Wa (mm)	1423	1423
Travel speed, laden/ unladen	km/ h	5/ 5.5	5/ 5.5
Lifting speed, laden/ unladen	m/ s	0.1	0.1
Lowering speed, laden/ unladen	m/ s	——	——
Maximum gradeability, laden/ unladen S2 5 min.	%	8/16	8/16
Drive motor rating S2 60 min.	kW	1.1	1.1
Lift motor rating at S3 15%	kW	2.2	2.2
Battery voltage/ rated capacity (5h)	V/ Ah	24/ 160	24/ 160
Battery weight (with box)	kg	120	120
Type of drive control		AC	AC
Manufacturer of Controller		ZAPI	ZAPI
