Help CenterFactory Supply Top Rink Quality 18hp Mini Tractor
Related Products
-
Factory Directly Supply Good Quality Mini Farm Tractor With Rotary MowerUS$ 1,000 - 1,250MOQ: 1 Set -
New Design Mini Tractors of 15HP Mini Tractor for Popular Sale in ChinaUS$ 800 - 950MOQ: 1 Set
-
New Design Hot Sale Mini Tractor With Plow From ChinaUS$ 800 - 950MOQ: 1 Set
-
15hp Electric Start Multi-purpose Farm Mini Tractor PlowUS$ 800 - 950MOQ: 1 Set
-
2015 Hot Sale 15hp Electric Start Multi-purpose Farm Mini Tractor With Mini TrencherUS$ 800 - 950MOQ: 1 Set
mini tractor
Combining with the advantages of walking tractor and four-wheel tractor,it is a kind of new small tractor,but the price is lower than wheel tractor and easier to operate for farmers with a higher efficent.
Main parameters of the mini tractor
Gearbox casing:Special steel casting box
Outline dimensions:2200×970×1120
Wheel base (mm):1150mm
Tread:Front wheel:850 Rear wheel:800
Min. ground clearance:210mm
Turning round radius :2m
Structure Weight:542kg
Theoretical speeds(km/h)
Shift |
I |
Ⅱ |
Ⅲ |
Iv |
v |
VI |
RⅠ |
RⅡ |
|
Speed (Km/h) |
2.1 |
3.8 |
5.3 |
8.6 |
13.3 |
21.5 |
1.62 |
6.6 |
Main engine parameters of the mini tractor
Engine Model |
CF1300 |
Structure |
Single cylinder, Horizontal, Water cooled, Four stroke |
Rated speed r/min |
2200 |
Rated power Kw |
13.12 |
Transmission system of the mini tractor
Clutch |
Dry, Dual action |
Differential type(F/R) |
Closed/Symmetry bevel type |
Brake type |
Hoof type |
Connection method |
B3200 Triangle tape B3200 |
Walking & Steering of the mini tractor
Front axle |
Integral |
|
Tire Standar |
Front wheel |
4.00-10/4.00-12 |
Rear wheel |
6.00-12/6.5-16 |
|
Steering gear type |
Worm gear type/hourglass worm wheel type |
|
The front wheel toe-in |
6~12 |
|
The front wheel camber |
2°±30′ |
|
Kingpin inclination |
7°±15′ |
|
Reverse caster |
3°±15′ |
|
Hydraulic equipment of the mini tractor
Structure |
Half the metal |
Oil pump |
Single plunger/gear pump |
Opening pressure of safety valve(Mpa) |
16±0.5 |
Rated hoisting time (s) |
≤3 |
Electrical equipmmet of the mini tractor
Generator |
Permanent magnet flywheel generators |
14V 350W |
Lamp |
Headlight 12 v / 90 w |
|
Turn signal |
12V/8W |
|
Main filling quantity (L)
The hydraulic oil tank 2.2L
| Packaging Details: |
Wooden Case with Iron frame SKD 40HQ 52 sets / 20GP 24 sets |
|---|---|
| Delivery Detail: | 1~2weeks after getting deposit |
